Specifications
Brand Name :
LINO
Model Number :
GM48PSMS48
Certification :
ROHS,CE
Place of Origin :
ZHEJIANGNINGBO
MOQ :
1K
Price :
The price ranges from 28 to 40 RMB per unit. The specific model requirements vary
Payment Terms :
T/T
Supply Ability :
10,0000 units per month
Delivery Time :
30work days
Packaging Details :
Carton with pallet
Input :
<3W
Voltage range :
from 12VAC to 230VAC
Direction of rotation :
CW, CCW, FREE
Motor type :
PM synchronous motor
Noise :
<55dB
Shaft :
Customizable
clutch :
2 way clutch is available，slipping torque 7~11kg.cm
Description

AC gear motor GM48PSMS48

Products' type: AC geared motor

2-Way Clutch Tear Drop AC Gear Motor 150g 230V GM48PSMS48
Model: GM48PSMS48500
Sort: Pear shape AC synchronous geared motor
Typical applications: Valve,coffee machine, communications-equipment, ACU-RITE,induced garbage can, electronic lock, optical equipment, medical instrumentation, office equipment, household appliances,etc…
Weight 150g (approx)

Specifications UNIT GM48PSMS48500
Voltage VAC 24; 110; 230
Frequency Hz 50/60
Input W <=3W
Current A 0.012(230V)
Standard gear ratio

a:12.5, 15,25,41.7(125/3),83.3(244/3),164.2, 246.3, 308, 450,985,1846.875(max load:8kg.cm);

b: 34.6, 128.6, 400, 500, 600, 750, 2400,4500 (max load:15kg.cm)
Speed RPM 0.666666667 0.83 1.25 3.04 6 12 33.3
Torque Kg.cm 30 25 18 8 4 2 0.7
Noise dB <=60
Dielectric strength AC1800V / 1 SEC
Direction of rotation CW；CCW； CW/CCW(FREE)
Note Voltage and output shaft can be changed as customer's request.
Packing detail Carton, Size: 52X36X36CM; 100pcs/carton; G.W:18Kg.
