240g Lino 24v Dc Geared Electric Motors GMF8334 Square Geared Dc Motor CCW
240g Lino 24v Dc Geared Electric Motors GMF8334 Square Geared Dc Motor CCW
240g Lino 24v Dc Geared Electric Motors GMF8334 Square Geared Dc Motor CCW
240g Lino 24v Dc Geared Electric Motors GMF8334 Square Geared Dc Motor CCW
240g Lino 24v Dc Geared Electric Motors GMF8334 Square Geared Dc Motor CCW
240g Lino 24v Dc Geared Electric Motors GMF8334 Square Geared Dc Motor CCW
Specifications
Brand Name :
lino
Model Number :
GMF8334
Certification :
ROHS
Place of Origin :
ZHEJIANG NINGBO
MOQ :
1K
Price :
The price ranges from 30 to40 yuan per unit. The specific model requirements vary
Payment Terms :
T/T
Supply Ability :
50,000 units per month
Delivery Time :
30work days
Packaging Details :
Carton with pallet
Voltage range :
6VDC,12VDC,24VDC
Direction of rotation :
CW, CCW
Motor :
RS365,RS385,RS395
Shaft :
Customizable
Description

DC GEAR MOTOR GMF8334

Products' type: DC geared motor

240g Lino 24v Dc Geared Electric Motors GMF8334 Square Geared Dc Motor CCW
Model: GMF8334
Sort: Square shape DC geared motor
Typical applications: Valve,coffee machine, coin machine,communications-equipment, ACU-RITE,induced garbage can, electronic lock, optical equipment, medical instrumentation, office equipment, household appliances,etc…
Weight 240g (approx)

MODEL VOLTAGE AT NO LOAD AT MAXIMUM EFFICIENCY AT STALL
SPEED CURRENT SPEED CURRENT TORQUE TORQUE CURRENT
VDC RPM A RPM A mN.m kg.cm mN.m kg.cm A
GMF8334103.5-385 24 102 0.15 84 0.65 784 8.000 4606 47.000 2.9
Base motor option 365,385,395
Gear ratio option 103.5
Note The specifications and output shaft can be changed as customer's request.
Packing detail Carton, Size: 52X36X36CM;100pcs/carton; G.W:26.6Kg.

240g Lino 24v Dc Geared Electric Motors GMF8334 Square Geared Dc Motor CCW

240g Lino 24v Dc Geared Electric Motors GMF8334 Square Geared Dc Motor CCW
