Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment
Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment
Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment
Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment
Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment
Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment
Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment
Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment
Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment
Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment
Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment
Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment
Specifications
Certification :
3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949
Place of Origin :
Guangdong, China
Brand Name :
Linke
MOQ :
1000m
Price :
Negotiable
Packaging Details :
According to requirement
Delivery Time :
7-15 days
Payment Terms :
Advance 30% deposit and ship after receiving 70% final payment
Supply Ability :
50000m/day
Model NO. :
60227 IEC52(RVV) 60227 IEC53(RVV)
Conductor Material :
Copper
Sheath Material :
PVC
Material Shape :
Round Wire
Range of Application :
Electric Equipment Internal Wiring
Voltage :
300V/300V
Type :
Insulated
Conductor Type :
Twisted wire
Application :
Overhead, Heating, Underground
Customization :
Available
Shipping Cost :
about shipping cost and estimated delivery time.
Return&refunds :
You can apply for a refund up to 30 days after receipt of the products.
conductor material :
copper/Tinned Copper
Exterior material :
customize：PVC、PE、LSFOH、silicone rubber
insulating materials :
customize:PVC、PE 、XLPE、EPR、SIR
specifications :
0.1-450mm²
rated voltage :
300-600V
rated temperature :
-60± 200℃
Description
APPlication
Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment
  1. RVV implementation of the standard GB/T5023.5-2008
  2. the rated voltage is 602271EC52 (300/300V) 2271EC53 (300/500V)
  3. PVC sheath
  4. PVC insulation
  5. conductor multiple core return naked copper stranded
  6. Normal working temperature shall not exceed 70℃
  7. The product has passed CCC certification

Suitable for control signal transmission line, electrical equipment, instrumentation, automation equipment, security and anti-theft alarm system, high-rise building intercom system, household lighting connection line, etc

Product parameter information
Product name Product model Rated voltage Specifications Number cores
General purpose single core hard conductor sheathless cable 60227 IEC 01 (BV) 450/750V 1.5~50 Single core
General purpose single core flexible conductor sheathless cable 60227 IEC 02(RV) 450/750V 1.5~50 Single core
Single core flexible conductor sheathless cable 60227 IEC 06(RV) 300/500V 0.5~1.0 Single core
Copper core PVC insulated flexible cable BVR 450/750V 1.0~50 Single core
Copper core PVC insulated PVC sheathed shielded flexible wire RVVP 300/300V 0.3~6.0 2-16 cores
Copper core PVC insulated PVC sheathed flexible cable RVV 300/500V 0.3-2.5 6-16cores
Ordinary PVC sheathed wire 60227 IEC 53(RVV) 300/500V 0.75-2.5 2-5cores,round
color Conductor Normal Sections Certification Rated Voltage Standard Keyword Core Type Application Conductor Material Conductor Type Insulation Material Place of Origin Model Number
white,black,grey or OEM Flexible Copper 0.5mm²,0.75mm² ,1.0mm²,1.5mm²,2.5mm²,4.0mm²,6.0mm². CCC,CE, ISO9001 300/300V 300/500V IEC60227;GB/T5023;BS6500;VDE0281;JB/T8734 RVV flexible electric cable 2-40Core insulated Heating Copper/cca Stranded PVC Guangdong,China RVV
specification
Voltage grade (V) Cross-sectional Area (mm2) Conductor combination (mm) Insulation thickness (mm) Toplimit of overall diameter (mm)
300/500V 2x1.0 32/0.2 0.6 8.0
300/500V 2x1.5 48/0.2 0.7 9.0
300/500V 2x2.5 80/0.2 0.8 11.0
300/500V 2x4.0 128/0.2 0.8 12.4
300/500V 2x6.0 192/0.2 1.0 13.4
300/500V 3x1.0 32/0.2 0.6 9.4
300/500V 3x1.5 48/0.2 0.7 11.0
300/500V 3x2.5 80/0.2 0.8 13.0
300/500V 3x4.0 128/0.2 0.8 14.6
300/500V 3x6.0 192/0.2 1.0 16.0
300/500V 4x1.0 32/0.2 0.6 10.0
300/500V 4x1.5 48/0.2 0.7 12.0
300/500V 4x2.5 80/0.2 0.8 14.0
300/500V 4x4.0 128/0.2 0.8 16.5
300/500V 4x6.0 192/0.2 1.0 18.5
300/500V 5x1.0 32/0.2 0.6 10.0
300/500V 5x1.5 48/0.2 0.7 12.0
300/500V 5x2.5 80/0.2 0.8 14.0
300/500V 5x4.0 128/0.2 0.8 16.5
300/500V 5x6.0 192/0.2 1.0 18.5

Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment

Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment

Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment

Company Profile

Dongguan Jingtong wire and Cable Technology Co., Ltd. uphold the spirit of "fine copper seiko, Mingde

Flame Retardant UL Certified 300V/500V Industrial Control Shielded Cable for Electric Equipment

We have a strong R&D team,6 people in the engineering department,they all have more than 10 years of technology and experience in the field of wire and cable,professional focus on wire and cable solutions to ensure that we provide the most accurate and effective solutions to our customers.The quality control department has 10 people,from inxoming materials to shipping,esch step is strictly supervised to ensure that the products reach the customer's hands are 100% good.The production staff has more than 50 people, who are experienced in prodution.

FAQ
  • 1. Are you a manufacturer or trading company?
    We are a professional manufacturer. We can control your order from the first begining to the last. Welcome to visit us. We'll pick you up in Shenzhen.
  • 2. How can I get a sample to test your quality?
    The samples are free for you. New clients are expected to pay for the courier cost.
  • 3. What's your Minimum Order Quantity?
    Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.
  • 4. Can I get a discount?
    It depends on your quantity, We can make a discount and afford the freight. Pls kindly contact us.
  • 5. Does your company accept OEM production?
    Yes, could print your company name, we even custom the quality card to promote your company.

For More Information, Please do feel free to contact us!
