1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly
1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly
1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly
1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly
1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly
1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly
1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly
1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly
1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly
1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly
1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly
1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Linke
Certification :
UL;ISO9001;ISO13485;IATF16949;TPU
MOQ :
1000m
Price :
Negotiable
Packaging Details :
According to requirement
Delivery Time :
7-15 days
Payment Terms :
Advance 30% deposit and ship after receiving 70% final payment
Supply Ability :
50000m/day
Model NO. :
LK-EV15
AMP :
1200A
Color :
Customized
Plug Type :
IEC 62196-2 (Type 2), SAE J1772 Type 1
Conductor :
Bare Copper
Jacket :
Silicone
Use :
Charging
Samples :
US$ 1000/PCS 1 PCS(Min.Order) |
Customization :
Available
Return&refunds :
You can apply for a refund up to 30 days after receipt of the products.
conductor material :
copper/Tinned Copper
Conductor Type :
Twisted wire
Exterior material :
customize：PVC、PE、LSFOH、silicone rubber
insulating materials :
customize:PVC、PE 、XLPE、EPR、SIR
specifications :
0.1-450mm²
rated voltage :
300-600V
rated temperature :
-60± 200℃
type :
insulated
package :
By roll
Core :
Multiple
Lead Time :
7-15days
Description
Silicone Jacket Energy EV Charging Pile Wire Harnesses Assembly
High-performance EV charging cable assembly designed for reliable power transmission in electric vehicle charging applications.
Cable Specifications
Specification Cable Name EV Cable
Cable Spec 2C*80mm²+1C*25mm²+2C*4mm²+(3C*0.75mm²)(P2)+(7C*0.75mm²)
RoHS Compliant Yes
Conductor Details
Item Material Size O.D.(Ref.)
A: 2C*80mm² Bared copper stranded 2580/0.20 ±0.008mm 12.40±0.25mm
B: 1C*25mm² Bared copper stranded 798/0.20 ±0.008mm 7.00±0.20mm
C: 1C*4mm² Bared copper stranded 224/0.15±0.008mm +10/1#Tinsel+1000D Kevlar 2.70±0.15mm
D: (3C*0.75mm²)(P2) Bared copper stranded 40/0.15±0.008mm+10/0.19mmTinsel+200DKevlar 1.40±0.10mm
E: (7C*0.75mm²) Bared copper stranded 40/0.15±0.008mm+10/0.19mmTinsel+200D Kevlar 1.40±0.10mm
Insulation Properties
Material Min. Average Thickness Min. Thickness at Any Point O.D.
Thermoplastic (EF2585,85±3A) 1.60mm 1.34mm 15.60±0.40mm
Electrical Characteristics
Parameter Value
Rated Voltage DC 1000V
Rated Temperature Jacket -40~90ºC, Insulation -40~125ºC
Max. Conductor Resistance (20ºC) A:0.242Ω/km B:0.78Ω/km C:4.95Ω/km D&E:26Ω/km
Insulation Voltage Withstand AC 2.5kV/5min, leakage current ≤5mA
Completed Cable Voltage Withstand AC 3.5kV/15min, leakage current ≤5mA
Min. Insulation Resistance (20ºC) 500MΩ.km
Physical Properties
Property Value
Tensile Strength ≥20MPa
Elongation ≥300%
Min. Bend Radius 6*OD
Abrasion Resistance ≥2000 times
Product Images
1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly 1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly 1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly 1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly 1200A AMP Silicone Jacket EV Charging Cable with Customized Plug Type for Electric Vehicle Charging Assembly
Certifications & Standards
  • UL Standards: UL1007, UL1185, UL1672, UL10070, UL10483, UL1015, UL1569, UL10012, UL10269
  • Additional UL Certifications: UL2095, UL2129, UL2468, UL2586, UL2725, UL20233, UL20280, UL20963, UL2103, UL2463, UL2517, UL2587, UL2835, UL20276, UL20549, UL21198, 2104, UL2464, UL2576, UL2661, UL2919, UL20279, UL20886, UL21664
  • Quality Management: ISO9001, ISO13485, TS16949
  • CNR Appliance Wiring Material Compliance
Frequently Asked Questions
Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first beginning to the last. Welcome to visit us. We'll pick you up in Shenzhen.
How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.
What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.
Can I get a discount?
It depends on your quantity. We can make a discount and afford the freight. Please kindly contact us.
Does your company accept OEM production?
Yes, we can print your company name and even customize the quality card to promote your company.
