1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging
1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging
1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging
1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging
1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging
1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging
1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging
1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging
1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging
1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging
1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging
1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Linke
Certification :
UL;ISO9001;ISO13485;IATF16949;TPU
MOQ :
1000m
Price :
Negotiable
Packaging Details :
According to requirement
Delivery Time :
7-15 days
Payment Terms :
Advance 30% deposit and ship after receiving 70% final payment
Supply Ability :
100000000
Model NO. :
LK-EV12
AMP :
1200A
Color :
Customized
Customized :
Customized
Plug Type :
IEC 62196-2 (Type 2), SAE J1772 Type 1
Conductor :
Bare Copper
Structure :
3034/0.20
Jacket :
Silicone
Use :
Charging
Transport Package :
Roll
Specification :
95MM2
Trademark :
LINKE
Origin :
China
HS Code :
94054090
Package Size :
60.00cm * 55.00cm * 50.00cm
Package Gross Weight :
118.000kg
After-sales Service :
1year
Warranty :
1year
Samples :
US$ 1000/PCS 1 PCS(Min.Order) |
Customization :
Available
Shipping Cost :
about shipping cost and estimated delivery time.
  :
Initial Payment Full Payment
Currency :
US$
Return&refunds :
You can apply for a refund up to 30 days after receipt of the products.
conductor material :
copper/Tinned Copper
Conductor Type :
Twisted wire
Exterior material :
customize：PVC、PE、LSFOH、silicone rubber
insulating materials :
customize:PVC、PE 、XLPE、EPR、SIR
specifications :
0.1-450mm²
rated voltage :
300-600V
rated temperature :
-60± 200℃
colour :
customize
type :
insulated
package :
By roll
Core :
Multiple
Lead Time :
7-15days
Description
OEM ODM Power Engine Wiring Harness for Automotive Vehicles
Product Specifications
Specification Cable Name EV Cable
Cable Spec 2C×80mm²+1C×25mm²+2C×4mm²+(3C×0.75mm²)(P2)+(7C×0.75mm²)
RoHS Compliant Yes
Cable Components
Item Description
A 2C×80mm²
B 1C×25mm²
C 1C×4mm²
D (3C×0.75mm²)(P2)
E (7C×0.75mm²)
Conductor Specifications
Component Material Size O.D. (Ref.)
A Bared copper stranded 2580/0.20 ±0.008mm 12.40±0.25mm
B Bared copper stranded 798/0.20 ±0.008mm 7.00±0.20mm
C Bared copper stranded 224/0.15±0.008mm +10/1#Tinsel+1000D Kevlar 2.70±0.15mm
D Bared copper stranded 40/0.15±0.008mm+10/0.19mmTinsel+200DKevlar 1.40±0.10mm
E Bared copper stranded 40/0.15±0.008mm+10/0.19mmTinsel+200D Kevlar 1.40±0.10mm
Insulation Properties
Parameter Material Min. Average Thickness Min. Thickness at Any Point O.D.
All Components Thermoplastic (EF2585,85±3A) 1.60mm - 0.50mm 1.34mm - 0.35mm 15.60±0.40mm - 2.50±0.10mm
Electrical Characteristics
Parameter Value
Rated Voltage DC 1000V
Rated Temperature Jacket: -40~90ºC, Insulation: -40~125ºC
Max. Conductor Resistance (20ºC) A: 0.242Ω/km, B: 0.78Ω/km, C: 4.95Ω/km, D&E: 26Ω/km
Insulation Voltage Withstand AC 2.5kV/5min, leakage current ≤5mA
Completed Cable Voltage Withstand AC 3.5kV/15min, leakage current ≤5mA
Min. Insulation Resistance (20ºC) 500MΩ.km
Physical Properties
Property Value
Tensile Strength ≥20MPa
Elongation ≥300%
Min. Bend Radius 6×OD
Abrasion Resistance ≥2000 times
Cable Structure Reference
Type Conductor mm² Structure Conductor Material Insulation Material Insulation OD (mm) 20ºC Conductor Resistance (Ω/KM)
EV-YJ 1.5 48/0.20 Copper Silicone 2.90±0.15 ≤12.7
EV-YJ 2.5 80/0.20 Copper Silicone 3.50±0.15 ≤7.60
EV-YJ 4 128/0.20 Copper Silicone 4.30±0.15 ≤4.71
EV-YJ 6 196/0.20 Copper Silicone 5.10±0.20 ≤3.14
EV-YJ 10 322/0.20 Copper Silicone 6.70±0.20 ≤1.82
1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging 1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging 1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging 1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging 1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging 1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging 1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging
Key Features
  • Conductor: Flexible bare annealed copper wire
  • Insulation: High-quality silicone
  • Color options: Black, Orange, Red, Yellow, Blue jacket
  • Single & double insulated options available
  • SQ MM sizes (European style): 4 sq mm to 240 sq mm
  • AWG sizes (North American style): 0AWG-10AWG
  • Wide temperature range: -60°C to 200°C
  • Low viscosity appearance for easy installation
Quality Certifications
SO9001 and ISO13485, TS16949
CNR - Appliance Wiring Material
Extruded PVC Insulated Single, rated 105ºC, 1000V, Class I, Group A, B, or AB, FT1 and/or FT2
Extruded PVC Non-integral Jacketed Cable, rated 105ºC, 1000V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
Extruded TPU Non-integral Jacketed Cable, rated 80ºC, 300V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging
Frequently Asked Questions
Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first beginning to the last. Welcome to visit us. We'll pick you up in Shenzhen.
How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.
What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.
Can I get a discount?
It depends on your quantity. We can make a discount and afford the freight. Please kindly contact us.
Does your company accept OEM production?
Yes, we can print your company name, and we even customize the quality card to promote your company.
