3 Phase AC Induction Gear Motor AC 220V 120mm 400w 7IK400GU-SF
3 Phase AC Induction Gear Motor AC 220V 120mm 400w 7IK400GU-SF
3 Phase AC Induction Gear Motor AC 220V 120mm 400w 7IK400GU-SF
3 Phase AC Induction Gear Motor AC 220V 120mm 400w 7IK400GU-SF
3 Phase AC Induction Gear Motor AC 220V 120mm 400w 7IK400GU-SF
3 Phase AC Induction Gear Motor AC 220V 120mm 400w 7IK400GU-SF
3 Phase AC Induction Gear Motor AC 220V 120mm 400w 7IK400GU-SF
3 Phase AC Induction Gear Motor AC 220V 120mm 400w 7IK400GU-SF
3 Phase AC Induction Gear Motor AC 220V 120mm 400w 7IK400GU-SF
3 Phase AC Induction Gear Motor AC 220V 120mm 400w 7IK400GU-SF
Specifications
Brand Name :
CHE
Model Number :
7IK400GU-SF
Certification :
RoSH, REACH, ISO9001:2015
Place of Origin :
China
MOQ :
1 unit
Payment Terms :
T/T, D/P, Western Union, MoneyGram
Supply Ability :
As pre your request
Delivery Time :
3~7 working days for sample
Packaging Details :
Cartoons with plastic bag and foam
Voltage :
3ph220v, 3hp380v
Power :
400w
Frequency :
50Hz
Rated Speed :
1350rpm
Rated Torque :
2700Nm
Starting Torque :
5900Nm
Gear Ratio :
3/ 5/ 7.5/ 10/ 12.5/ 15/ 18/ 20/ 25/ 30......../ 180
OEM & ODM Service :
Available
Description

7IK400GU-SF Three Phase AC 220V 120mm 400w AC Induction Gear Motor

CHE AC Induction Gear Motor Features:

1. CHE provide round shaft gear motors and pinion shaft type gear motors, very convenient for your machines

2. Low energy consumption, superior performance, reducer efficiency up to 96%, low vibration, low noise.
3. Providing lead wire or box types

4. CHE induction gear motors have variable size and power:

6w 15w 25w 40w 60w 90w 120w 200w
60mm 70mm 80mm 90mm 90mm 90mm 90mm 104mm

5. Widely used in those industries

* Metering Pump
* Consumer Electronics
* CNC Machines
* Drones
* Packing Machine
* Semi-conductor production Lines
* Industrial Automation
* Printers & Copiers
* Robotics
* Logistic Transimission

6.AC Types: Speed Control Gear Motors; Brake Gear Motors; Torque Gear Motors; Reversible Gear Motors; Speed Control Gear Motors; Right Angle Gear Motors; Motor Speed Controller;

DC Types: Brush DC Gear Motor; Brushless DC Gear Motors; Brush Planetary Gear motor; Brushless Planetary Gear Motor;

High Precision Planetary Gearboxes: Helical Gear & Spur Gear type;

3 Phase AC Induction Gear Motor AC 220V 120mm 400w 7IK400GU-SF

List of AC Induction Motor with Gearbox Characteristics:

Motor Model Output Power Voltage Frequency Current Rated Speed Rated Torque Statring Torque Capacitor
Pinion Shaft Round Shaft W V Hz A r/min mN.m mN.m μF/VAC
7IK400GU-SF 7IK400A-SF 400 3ph220 50 2.2 1350 2700 5900 /
7IK400GU-S3F 7IK400A-S3F 400 3ph380 50 1.2 1350 2700 5900 /

Gear Motor Reduction Ratio:

Gear Ratio 3 3.6 5 6 7.5 9 10 12.5 15 18 20 25 30 36 50 60 75 90 100 120 150 180
50Hz Speed (r/min) 450 375 270 225 180 150 135 108 90 75 67.5 54 45 37.5 3.7 22.5 18 15 13.5 11.3 9 7.5
Torque(Nm) 6.5 10.9 16.4 21.8 24.5 29.5 35.4 39.3 49.2 59.0 78.7 88.5 106.2 120 120 120 120 120 120 120 120 120

Round Shaft Gear Motor Drawings:

3 Phase AC Induction Gear Motor AC 220V 120mm 400w 7IK400GU-SF

Lead Wire Type Motor + Standard Gearbox Drawings:

3 Phase AC Induction Gear Motor AC 220V 120mm 400w 7IK400GU-SF

Gear Motor Wiring Diagram:

  • The direction of motor roation is as viewed from the shaft end of motor CW represents the clockwise direction, while CCW represents the couterclockwise direction.
  • Name indicated in the list is pinion shaft type gear motor, but is also foe the round shaft type gear motor.

3 Phase AC Induction Gear Motor AC 220V 120mm 400w 7IK400GU-SF

Pls note:

  • Change the direction of the single-phase motor rotation only after the motor stop work
  • If an attempt is made to change the direction of rotation while the motor is rotating, motor may ignore reversing command or appearing delay in changing its direction of rotation.
