F6D250 250W 12v Bushed DC Gear Motor 104mm For Robotic Automation
F6D250 250W 12v Bushed DC Gear Motor 104mm For Robotic Automation
F6D250 250W 12v Bushed DC Gear Motor 104mm For Robotic Automation
F6D250 250W 12v Bushed DC Gear Motor 104mm For Robotic Automation
F6D250 250W 12v Bushed DC Gear Motor 104mm For Robotic Automation
F6D250 250W 12v Bushed DC Gear Motor 104mm For Robotic Automation
F6D250 250W 12v Bushed DC Gear Motor 104mm For Robotic Automation
F6D250 250W 12v Bushed DC Gear Motor 104mm For Robotic Automation
F6D250 250W 12v Bushed DC Gear Motor 104mm For Robotic Automation
F6D250 250W 12v Bushed DC Gear Motor 104mm For Robotic Automation
Specifications
Brand Name :
CHE
Model Number :
F6D250
Certification :
RoSH, REACH, ISO9001:2015
Place of Origin :
China
MOQ :
1 unit
Payment Terms :
T/T, D/P, Western Union, MoneyGram
Supply Ability :
As pre your request
Delivery Time :
3~7 working days for sample
Packaging Details :
Cartoons with plastic bag and foam
Voltage :
12v, 24v, 48v
Power :
6w 10w 15w 25w 40w 60w 90w 120w 20w 250w
Rated Speed :
1800rpm 3000rpm
Brush Life :
2000 hours
Gear Ratio :
3/ 3.6/ 5/ 7.5/ 10/ 12.5/ 15/ 18/ 20/ 25/ 30......../ 200
OEM & ODM Service :
Available
Efficiency :
Ie 3
Description

F6D250 250W 12v Bushed DC Gear Motor 104mm for Robotic Automation

F6D250 250W 12v Bushed DC Gear Motor 104mm For Robotic Automation

A brush motor is a permanent type brush DC motor. A brush motor can also be called a "brushed motor", "permanent-magnet field type commutator motor", "governorless motor", or "permanent-magnet DC motor". These motors are most commonly used for models, automobile auxiliary devices, and other applications all over the world. If you have any questions regarding the requirement of controllers to use, please contact our engineering team.

Motor Parameters:

Model Voltage Power No-load Parameter Load Parameter Brush lLife Motor Weight
Speed Current Speed Torque Current
V W r/min A r/min mN.m A H kg
F6D250-12 12 250 3550 3.5 3000 795 27.4 2000 3.2
F6D250-24 24 250 3500 1.5 3000 795 13.7 2000 3.2
F6D250-48 48 250 3350 0.9 3000 795 6.7 2000 3.2
F6D250-12 12 250 1300 2.5 1800 1326 27.6 2000 3.2
F6D250-24 24 250 2250 1.2 1800 1326 13.9 2000 3.2
F6D250-48 48 250 2150 0.5 1800 1326 6.8 2000 3.2

  • Motor voltage, power and speed will be customized according to your requirements under allowed circumstance.
  • For external brush motor, customer can replace the brush directly. For internal ones, we need to disaaembly the motor first. F6D series motor is external motor

Model Gear Ratio 3 3.6 5 6 7.5 9 10 12.5 15 18 20 25 30 36 40 50 60 75 90 100 120 150 180 200
F6D250-24-30S Speed (r/min) 999 833 600 500 400 333 300 240 200 166 150 120 100 83 75 60 50 40 33 30 25 20 16.5 15
Torque (N.m) 1.93 2.32 3.22 3.86 4.83 5.8 5.8 7.24 8.69 10.43 10.43 13.04 15.65 18.8 20.9 26.1 31.3 39.1 40 40 40 40 40 40
F6D250-24-18S Speed (r/min) 600 500 360 300 240 200 180 144 120 100 90 72 60 50 45 36 30 24 20 18 15 12 10 9
Torque (N.m) 3.22 3.87 5.37 6.44 8.06 9.67 10.74 12.08 14.5 17.4 19.33 21.75 26.1 32.31 34.8 40 40 40 40 40 40 40 40 40

Brush DC Gear Motor Drawings:

F6D250 250W 12v Bushed DC Gear Motor 104mm For Robotic Automation
