Three-in-one 5 Axis Dental Milling Machine A5 For Lab
Three-in-one 5 Axis Dental Milling Machine A5 For Lab
Three-in-one 5 Axis Dental Milling Machine A5 For Lab
Three-in-one 5 Axis Dental Milling Machine A5 For Lab
Three-in-one 5 Axis Dental Milling Machine A5 For Lab
Three-in-one 5 Axis Dental Milling Machine A5 For Lab
Three-in-one 5 Axis Dental Milling Machine A5 For Lab
Three-in-one 5 Axis Dental Milling Machine A5 For Lab
Specifications
Brand Name :
LEOTECH
Certification :
CE
Place of Origin :
Chongqing, China
MOQ :
1 set
Price :
$9000/sets
Product Name :
Three-in-one Five-axis Milling Machine A5
Processing Method :
5-Axis 5-Control Dry/Wet cutting
Weight :
≈120kg
Dimension :
≈540mm*700mm*680mm
Cuttable materials :
Wax/zirconia/resin/glass ceramics/premilled abutment
Spindle Speed :
0 ~ 60000rpm
Power Source :
Electric
Warranty :
1 Year
After-sale Service :
Online technical support
Shelf Life :
1 Year
Quality Certification :
CE
Instrument classification :
Class II
Description

Three-in-one Five-axis Milling Machine A5

Three-in-One Five-Axis Milling Machine A5: Unified Wet/Dry Processing Center
Engineered to eliminate the need for multiple dedicated systems, the A5 combines wet cutting, dry milling, and automated tool management in a single footprint (540×700×680mm). Its gantry structure delivers vibration stability under 5μm – critical for titanium abutments and thin-wall veneers requiring ±8μm accuracy. The 6-tool carousel with auto-calibration slashes changeover time to 11 seconds between material types.

Triple-Function Innovation

  • Hybrid Processing: Switch between wet/dry modes without recalibration

  • Smart Tooling: RFID-tagged cutters prevent material cross-contamination

  • Remote Diagnostics: Real-time performance analytics via encrypted cloud

Material-Specific Advantages

Material Specialized Feature Tolerance
Zirconia Layered sintering mode ±10 μm
Titanium Vortex chip evacuation ±15 μm
Glass Ceramics Thermo-stabilized bed ±8 μm
Wax Composites Low-temp machining ±20 μm

Technical Superiority
• 5-Axis Simultaneous Control: 0-60,000 RPM spindle processes 45° angled geometries
• 98mm Fixture Compatibility: Handles discs/blocks/pre-milled abutments
• 2kW Direct-Drive Motor: Maintains torque at 55,000 RPM

Critical Applications
→ Full-crown zirconia in 18 minutes
→ 6-unit implant bridges (titanium)
→ 0.3mm ultra-thin veneers
