Specifications
Brand Name :
LEOTECH
Certification :
CE
Place of Origin :
Chongqing, China
MOQ :
1 set
Price :
$9000/sets
Product Name :
Three-in-one Five-axis Milling Machine A5
Processing Method :
5-Axis 5-Control Dry/Wet cutting
Weight :
≈120kg
Dimension :
≈540mm*700mm*680mm
Cuttable materials :
Wax/zirconia/resin/glass ceramics/premilled abutment
Spindle Speed :
0 ~ 60000rpm
Bur capadity :
6
Cutter size :
Axis diameter: 4mm, length:45-55mm
Application :
Full crown,coping crown,inlay,veneer,crown and bridge,etc.
Power Source :
Electric 2KW
Warranty :
1 Year
After-sale Service :
Online technical support
Shelf Life :
1 Year
Quality Certification :
CE
Instrument classification :
Class II
Jip :
The diameter of disk, block and premilled abutment is 98mm
Structure :
Gantry Structure
Description

Clinic-Optimized Dental Milling Solution: A5 Three-in-One System

Designed specifically for space-constrained clinics, the A5 delivers lab-grade results in 0.8m². The capacitive touchscreen enables single-operator control of complex workflows – from wax try-ins to final zirconia crowns – with 90% noise reduction (62 dB) compared to conventional mills. Its ISO 10993-certified sealed chamber contains particulate emissions during dry milling.

Chairside Workflow Revolution

STEP

TIME SAVING
CLINICAL BENEFIT
Tool Change
78% faster

Same-day multi-case

Material Switching

No recalibration

Wax-to-zirconia in 1 session
Remote Maintenance
30min resolution

Zero on-site downtime

Key Technical Features

  • Open Architecture: Compatible with major CAD software (ex: exocad, 3Shape)

  • Auto Recovery: Saves jobs during power interruptions

  • HEPA Filtration: Optional add-on for allergen-sensitive environments

Procedure-Specific Performance
▸ Inlays/Onlays: 12-14 minutes
▸ 3-unit bridge: 22 minutes
▸ Custom abutments: 8 minutes

Preventative Maintenance System
• Self-lubricating linear guides (2,000-hour service interval)
• Humidity-controlled electronics compartment
• Tool breakage sensors with auto-pause

Product Comparison Reference Table

Model Processing Max. Material Tool Capacity Footprint Ideal Setting
A5 Wet/Dry Hybrid Ø98mm 6 tools 0.8m² Clinics/Labs
LT02 Wet Primarily Wet Ø120mm 10 tools 1.2m² Production Labs
LT01 Dry Dry Only Ø98mm 8 tools 1.0m² High-Volume Labs
