P8 High Luminance Outdoor Rental LED Display panel with IP65 waterproof for star hotel
P8 High Luminance Outdoor Rental LED Display panel with IP65 waterproof for star hotel
P8 High Luminance Outdoor Rental LED Display panel with IP65 waterproof for star hotel
P8 High Luminance Outdoor Rental LED Display panel with IP65 waterproof for star hotel
Specifications
Brand Name :
Shenzhen LED World
Model Number :
LW-RO 8
Certification :
CE,RoHS,FCC,CCC
Place of Origin :
China
MOQ :
1 square meter
Price :
negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
2000 sqm/month
Delivery Time :
12~20 working days after deposit received
Packaging Details :
Carton/Plywood case/Flight case etc.
Green LED :
SMD3535, 1800-2000 MCD
Pixel Pitch (mm) :
8mm
LED Type :
3535
Operating temperature/humidity :
temperature：-20℃～ 50℃ humidity：10～90%RH
IP Grade :
IP65/IP43
Max.power (W/m2) :
700
Refresh Rate(Hz) :
1920
Color Depth :
65536
Cabinet weight(kg) :
17
Cabinet Size(mm) :
640×640×80
Description

outdoor rental 640x640mm-P5,P8,P10.pdf

P8 High Luminance Outdoor Rental led panel with IP65 waterproof for star hotel

P8 Outdoor Rental led panel feature:

  1. Kinglight LED lamp and Macroblock 5124 made;
  2. High brightness Waterproof;
  3. Super slim and hanging design make it easy and fast for assembling and disassembling;
  4. Auto-adjustment of brightness accordingto external environment,thus no light pollution;
  5. Wide viewing angle: The horizontal and vertical viewing angles are so wide that it is suitable for wide horizon;
  6. IP65 waterproof, front and rear side;
  7. Ultra-light: size of the cabinet is 480mm*480mm, the weight only4-6kg per set;

P8 Outdoor Rental led panel advantage:

  1. High Contrast ratio: 4000:1,This is a very high level to ensure a vivid image of our LED display screen system;
  2. Easy installation and dismantling, without any tools, it takes only 6 seconds to assemble one cabinet, any cabinet within the screen is free of assembly and dismantling;
  3. Wooden case or flight case,you are the both;
  4. Die cast aluminum structure, great durability;
  5. Large Viewing Angle: Broad viewing angle up to 120°, bring a larger visible area;

P8 Outdoor Rental led panel Parameter:

Modules:

No. Parameter Value
led type brightness Wave Length H/V Visual angle
1 Red LED SMD3535 600-800 MCD 620-625nm 140°/120°
2 Green LED SMD3535 1800-2000 MCD 520-525nm 140°/120°
3 Blue LED SMD3535 400- 600 MCD 470-475nm 140°/120°
4 Pixel Pitch (mm) 8mm
5 Pixel density(pix/m2) 15625
6 LED Type 3535
7 Viewing Angle X,Y120°
8 Module Size (mm) 320×160×16
9 Brightness(nits) ≥5000
10 Drive Method 1/5

Cabinets:

Cabinet Size(mm) 640×640×80
Cabinet Material Die casting aluminum
Cabinet weight(kg) 17

Electricity:

Color Depth 65536
Refresh Rate(Hz) 1920
Voltage 110-240V
Average.power(W/m2) 230
Max.power (W/m2) 700
IP Grade IP65/IP43
Operating temperature/humidity temperature:-20℃～ 50℃ humidity:10～90%RH
Storage temperature/ humidity temperature:-40℃～ 60℃ humidity:10～90%RH
Lifetime(h) ≥50000
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.

Why choose us:

  1. With more than 10 years experience in led display producing,equipments are update dregularly;
  2. Fast Delivery,Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
  3. inventory will be used to maintain your uninterrupted supply of the products;

FQA:
Q1: What's the pixel pitch for Indoor LED Display Screen ?
A1: Outdoor (6mm / 8mm/ 10mm)
Q2: How about the size of project?
A2: Please offer the size with "width by height" of project. We will offer the suitable solution for your project size,I will appreciate it if any drawing files about installation offered;
Q3:Could you alow a trial order?
A3:Yes.We are alowing to a trial order. This would enable you to see the high quality of our product and give you the opportunity to test it’s superiority;
Q4: What's the controlling system?
A4: Our standard controlling system for this model is Novastar.Also support other controlling system, like Linsn, etc;

P8 Outdoor Rental led panel ​Project case:

P8 High Luminance Outdoor Rental LED Display panel with IP65 waterproof for star hotel
