1FTX4FT LED Troffer Lights Gloss White Painting 2000lm-3500lm
1FTX4FT LED Troffer Lights Gloss White Painting 2000lm-3500lm
1FTX4FT LED Troffer Lights Gloss White Painting 2000lm-3500lm
1FTX4FT LED Troffer Lights Gloss White Painting 2000lm-3500lm
1FTX4FT LED Troffer Lights Gloss White Painting 2000lm-3500lm
1FTX4FT LED Troffer Lights Gloss White Painting 2000lm-3500lm
1FTX4FT LED Troffer Lights Gloss White Painting 2000lm-3500lm
1FTX4FT LED Troffer Lights Gloss White Painting 2000lm-3500lm
Specifications
Brand Name :
Noonlight
Model Number :
N-TR-1X4FT
Certification :
DLC / ETL / RoHS
Place of Origin :
China
MOQ :
200
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, Paypal
Supply Ability :
10000 Piece/Pieces per Month
Delivery Time :
30+ working days
Packaging Details :
1pc/inner box, 4pcs/CTN,
Product Name :
DLC5.1 Premium LED Troffer
Input Voltage(V) :
AC 120-277VAC or AC 120-347VAC
Power :
27W-24W-20W-16W Power Adjustable
CCT :
30K/35K/40K/50K Tunable
Luminous Efficacy :
130 lm/W
Housing :
24 Gauge Steel, Gloss White Painting
Light Source :
2835 SMD, CRI>80
Installation :
Surface Mounted, Suspension Mounted
Warranty :
5 years
Certificate :
ETL/DLC 5.1 Preminum
DLC Category :
Stairwell and Passageway Luminaires
Description

1FTX4FT LED Troffer Lights Gloss White Painting 2000lm-3500lm

1FTX4FT LED Troffer Lights Gloss White Painting 2000lm-3500lm

  • Noonlight LED Troffers are the super slim led fixtures for fluorescent troffers in new or remodel construction. CCT and wattage adjustable technology enables customers to choose the color temperature and lumen output that is best suited for their lighting application.
  • Frosted lens delivers even light with excellent color rendering and low glare, while its architectural design features make it the perfect complement to office, education, health care, hospitality and retail interiors.

Features

  • CCT and Power Tuanable LED Troffer Light UP TO 135LM/W
  • CLASS P Programmable LED Driver, 4 Step Power Adujustable,
  • CRI>80, CCT Tunable, 3000K, 3500K, 4000K and 5000K
  • Minimize stock, 1 SKU can cover max. of 16 models.
  • An auxiliary to connect low voltage sensor/BLE or other IOT network.
  • 2 Depth Design: Super Thin & Standard
  • 5-100% 0-10V dimmable, flicker free, Dim to off.
  • DLC5.1 Premium LED Troffer Built-in PIR Sensor and Motion Sensor Options.
  • Built-in Emergency Driver Option.
  • L70>50,000hrs, 5 year warranty.

Specification

Model No DLC Input Voltage Wattage Lens CRI/CCT Rated Lumen @ 30K

Rated

Efficancy

@ 30K

 Viewing Angle

Rated Lifetime

Replacing

N-TR-14-27-XX-WC1

 P

120-347VAC/

120 - 277VAC 0- 10V Isolated

Dimmable

 27W Frosted

Ra>80,

30K

35K

40K

50K

3375LM

125LM/W

 120°

L70>

50000hrs

60W - 200W

Incandescent

N-TR-14-24-XX-WC1

 P

120-347VAC/

120 - 277VAC 0- 10V Isolated

Dimmable

 24W Frosted

Ra>80,

30K

35K

40K

50K

3000LM

125LM/W

 120°

L70>

50000hrs

60W - 200W

Incandescent

N-TR-14-20-XX-WC1

 P

120-347VAC/

120 - 277VAC 0- 10V Isolated

Dimmable

 20W Frosted

Ra>80,

30K

35K

40K

50K

2500LM

125LM/W

 120°

L70>

50000hrs

60W - 200W

Incandescent

N-TR-14-16-XX-WC1

 P

120-347VAC/

120 - 277VAC 0- 10V Isolated

Dimmable

 16W Frosted

Ra>80,

30K

35K

40K

50K

2000LM

125LM/W

 120°

L70>

50000hrs

60W - 200W

Incandescent

CCT and Power Tuanable LED Troffer Light Accessories

1FTX4FT LED Troffer Lights Gloss White Painting 2000lm-3500lm

4W or 8W UL Listed Emergency Backup

  • Listed for field Instllation-UL924 & CSA C22.2 NO. 141
  • Input: 120-277VAC/347VAC 50/60Hz
  • Output: 25-50VDC, 8W or 15w
  • Illumination Time: 90min
  • Battery Type:Li-ion/Ni-MH
  • Battery Recharge Time: 24Hrs
  • Surge Protection: 3KV
  • Protection:
  • Input over-current Protection (Fuse)
  • Output over-voltage Protection
  • Output Low Voltage Protection
  • Output Short Circuit Protection
  • Working Temp.: 10℃ to 50℃

Advantages

HOW TO CHANGE THE WATTAGE & CCT IN THIS FIXTURE

Power Adjustable Slide Switch Position

Size/Positon

0

1

2

3

1X4

27W

24W

20W

16W

2X2

27W

24W

20W

16W

2X4

40W

30W

25W

20W

CCT Tunable Slide Switch Position

Position/Group

CCT

Low

3000K(Optional)

Middle 1

3500K

Middle 2

4000K

High

5000K

Manufacturing Abilities

Noonlight offers One stop supply chain service to our clients, all of the processes are made in house, such as lasering, punching, bending, welding, painting, smt and assemblies.

1FTX4FT LED Troffer Lights Gloss White Painting 2000lm-3500lm

Certificate

1FTX4FT LED Troffer Lights Gloss White Painting 2000lm-3500lm

CCT and Power Tuanable LED Troffer Light Applications

Schools, offices, conference room, hospitality etc.
