Specifications
Brand Name :
BAKO VISION
Model Number :
BOF
Certification :
CCC, CE, FCC, ETL
Place of Origin :
CHINA
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100,00 sqm / month
Delivery Time :
20 days
Packaging Details :
Plywood Case/ Flight Case
Pixel Configuration :
SMD 3535
IP Rating(Front/Rear) :
IP65/ IP54
Expected Lifetime :
11 Years
Module Demensions (W*H)(mm) :
192*192
Gray Scale (mm) :
16bit
Mtbf :
More 50, 000 Hours
Refresh Rate :
>1920 Hz
Description

P5-P10mm Wifi/ 4G/USB/Cloud Control Outdoor Commercial Advertising Billboard

Key Specifications:

Outdoor Commerical Fixed LED Display:

  • Pixel Pitch:P5,P6,P8,P10.
  • Cabinet Size:Can be customized
  • Relatively low cost (factory), meets your budget
  • Stable capability, pass professional testing
  • Easy installment and low maintenance cost
  • Waterproof and dustproof: IP65
  • Large viewing angle: H:140°, V:160°
  • Good heat emission capability,Aluminum or steel cabinet
  • Exported to 120+ countries .


Outdoor Commerical Fixed LED Advantages:

  • Frequently-used outdoor full color led screen.
  • High quality and brightness. Wide color space and long lifespan.
  • Adopting high reliability and antistatic led chips from famous factory automatic equipment producing.
  • Constant current, led panel and driving panel is designed separately,which improve reliability and maintainability.
  • High quality sealed silicone , passing by water spraying test before delivery.
  • High accuracy and numerical control metal plate cabinet.

P5-P10mm WiFi/ 4G/USB/Cloud Control Outdoor Commercial Advertising Billboard

Outdoor Commerical Fixed Specifications

BOF-6 BOF-8 BOF-10
Physical Pitch 6.67 mm 8 mm 10 mm
Pixel Configuration SMD 2727 SMD 3535 SMD 3535
Pixel Density 22,500 pixels/m² 15,625 pixels/m² 10,000 pixels/m²
Module Dimensions(W*H)(mm) 256*256 256*256 256*256
Panel Dimensions(mm) 1280*768*150 1280*768*150 1280*960*150
NO. of Modules Per Panel (W*H) 4*3 5*3 4*3
Physical Resolution of Module (W*H) 48*48 32*32 32*32
Physical Resolution of Panel (W*H) 192*144 160*96 128*96
Panel Material Steel/ Aluminum Steel/ Aluminum Steel/ Aluminum
Colors 281 trillion 281 trillion 281 trillion
Brightness >6,500 nits >6,500 nits >6,500 nits
Weight (kg/m²) 65/45 65/45 65/45
Processing 16 bit 16 bit 16 bit
Refresh Rate >1920 Hz >1920 Hz >1920 Hz
IP Rating IP65/ IP54 IP65/ IP54 IP65/ IP54
Viewing Angle V:160 degree
H: 140 degree
V:160 degree
H: 140 degree
V:160 degree
H: 140 degree
Expected Lifetime 100,000 Hrs 100,000 Hrs 100,000 Hrs
Operating Temp/Humidity -20ºC-50ºC/
10%-90%
-20ºC-50ºC/
10%-90%
-20ºC-50ºC/
10%-90%
Storage Temp/Humidity -20ºC-50ºC/
10%-90%
-20ºC-50ºC/
10%-90%
-20ºC-50ºC/
10%-90%
Avg./ Max. Power Consumption 360/900W/ panel 360/900W/ panel 360/900W/ panel
Servicing Front/Rear Front/Rear Front/Rear


Procesure Details

Supporting kinds of communication types like internet access, USB, 4G,WIFI and cloud control.

Light sensor ,
Automatically brightness adjustment, real-time display temp and humidity.

P5-P10mm WiFi/ 4G/USB/Cloud Control Outdoor Commercial Advertising Billboard


Main Export Markets:

  • North America
  • South America
  • Europe
  • Asia
  • Mid East/Africa
  • Pacific

P5-P10mm WiFi/ 4G/USB/Cloud Control Outdoor Commercial Advertising Billboard



Widely Application:

Our products have been widely used in venues as banks, stock exchange centers, schools, telecommunications, customs, stadiums, studio, shopping malls, railways, airports, harbors, city squares, courts, schools, restaurants etc



P5-P10mm WiFi/ 4G/USB/Cloud Control Outdoor Commercial Advertising Billboard


Our company
LED Vision Technology Limited  , started in Shenzhen in 2005, fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.Main markets are among America, Europe, Middle East and Asia.

P5-P10mm WiFi/ 4G/USB/Cloud Control Outdoor Commercial Advertising Billboard

Tips:
Package: Wooden package, Flight case.
Shipment:By road,sea and air
Delivery time:20-25 working days
Payment: T/T, 30% deposits, 70% balance before delivery
Shipping port: Shenzhen,China
Warranty time: 2 years

Price term: EXW Shenzhen


Service:
1) Your inquiries related to our products or prices will be replied in 24H
2) Well-trained and experienced staffs to answer all your enquire in fluent English
3) Customized design is available, OEM and ODM are accepted
4) Protection of your sales area, ideas of design and all your private information
5) Technology training
(A) We provide the technical training for free, which contains the operation training and maintenance training in the factory
(B) We will send our engineers to your country if necessary.
