Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access
Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access
Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access
Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access
Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access
Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access
Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access
Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access
Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access
Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access
Specifications
Brand Name :
Bako Vision
Model Number :
BOF
Certification :
CE,CCC,UL
Place of Origin :
China
MOQ :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
8000sqm/month
Delivery Time :
20~25 days
Packaging Details :
Plywooden case
Physical Pitch :
6.67mm
Module Size :
320*320mm
Cabinet Size :
960*960mm
No. Of Modules Per Panel (W*H) :
3*3
Panel Material :
Steel/Aluminum
Weight(sqm) :
65/45
Gray Scale :
16 bit
Colours :
281 trillion
Contrast Ratio :
2,000:1
Avg Power Consumption :
360W/sqm
Max Power Consumption :
900W/sqm
Brightness :
6500nits
Refresh Rate :
1920Hz
Vertical Viewing Angle :
160°
Horizontal Viewing Angle :
140°
Expect Lifetime :
100,000Hrs
Servicing :
Front
Operating Temp/Humidity :
-20℃-50℃/10%-90%
Storage Temp/Humidity :
-20℃-50℃/10%-90%
IP Rating :
IP65
Price :
Negotiation
Description

Outdoor Fixed LED Display P6.67 P10 Full Color Front Service LED Display Screen for Advertising

9-BOF-B.pdf

Outdoor Fixed LED Display Features:
1. High difinition, wonderful visual performance;

Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access

2. Multifunctional Module Buckle

Special multifuntional module buckle designed for adjusting gaps between module and cabinet to ensure the smoothness and alignment

Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access

3. Outdoor Rated

IP65

Brightness adjustable for day and night

Durable LED for 7/24 work mode

Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access

4. Fast Installation and Easy Maintenance

Fast lock system guarantees a quick and easy installation

Mechanica Front Access

Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access

5. Energy-Saving Technology

Cutting edge'cold display' technology

60% power lower than nomal

50% temperature less than normal

Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access

6. High Gray Scale

Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access

7. Different Installation

Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access

Outdoor LED Display Specification

Model BOF-6
Pixel Pitch 6.67mm
Pixel Density 22376 pixels/m2
LED Type SMD2727
LED Configuration 1R1G1B
Cabinet Dimension 960mm*960mm
Cabinet Resolution 144*144pixels
Weight 65/45 kg/sqm
Cabinet Material Steel/Aluminum
Ingress Protection
(front/rear)		 IP65/IP54
Brightness >6500nits
Viewing Angle(H/V) 140°/140°
Driving Method 1/6 scan
Frame Refresh ≥ 60Hz
Data Refresh Rate >1500Hz
Gray Scale 16bit
Power Consumption(avg. ) 300W/m2
Input Voltage AC 110/220±10%
50~60Hz
Temperature
(operating/storage)		 -20~50°C / -40~60°C
Humidity(operating/storage) 10%~90%RH
/ 10%~85%RH
MTBF ≥1000hrs
Life Span ≥100000hrs
Pixel Failure <0.0003

Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access

Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access

Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access

Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access

Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access

Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access

Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access

Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access

Outdoor Fixed LED Display Steel / Aluminum Panel P6.67 Full Color Back Access

Advantage:

1. Professional installation instructions

Our company also can arrange our engineers to provide you professional installation guide and training for free via remote control, video and phone.

2. Promising the goods quality

All of products will be tested many times and 100% promise the products are well before shipping.

3. Customized products

The products can be customized according to your projects and offer you the CAD drawing for free.

4. After-sale service

We guarantee all of our displays, modules, spare parts for full two years. During the time, we will replace or fix our goods for free if there is something wrong with them.
