Waterproof IP65 Front Service LED Display High Brightness Fast Lock
Waterproof IP65 Front Service LED Display High Brightness Fast Lock
Waterproof IP65 Front Service LED Display High Brightness Fast Lock
Waterproof IP65 Front Service LED Display High Brightness Fast Lock
Waterproof IP65 Front Service LED Display High Brightness Fast Lock
Waterproof IP65 Front Service LED Display High Brightness Fast Lock
Waterproof IP65 Front Service LED Display High Brightness Fast Lock
Waterproof IP65 Front Service LED Display High Brightness Fast Lock
Waterproof IP65 Front Service LED Display High Brightness Fast Lock
Waterproof IP65 Front Service LED Display High Brightness Fast Lock
Specifications
Brand Name :
Bako Vision
Model Number :
BOF
Certification :
CCC.CE.ETL.FCC
Place of Origin :
China
MOQ :
Negotiation
Price :
$399~999
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000 m²/month
Delivery Time :
20 days
Packaging Details :
Flight Case/ Wooden Case
Pixel Pitch :
5mm
Panel Material :
Steel/Aluminum
Processing :
16 bit
Refresh Rate :
>1920 Hz
Brightness :
>5000 Nits
Servicing :
Front/Rear
Colors :
281 trillion
Contrast Ratio :
2000:1
Description

IP67 Outdoor Fixed LED Display Screen Full Color High Brightness Fast Lock Front Service for billboard

BOF Series

SMD P5 Outdoor LED Display

1. Brightness: ≥6500cd/m2
2. Average power consumption: ≤360 W/m2
3. Manufacturer: over 15 years
4. Quick response: replying inquiry within 24hrs
5. Quality guarantee: CE, RoHS, FCC, IP65, ISO9001 + 100% testing before shipping.


Specification

BOF-4 BOF-6 BOF-8 BOF-10
Physical Pitch 4.81 mm 6.67 mm 8 mm 10 mm
Pixel Configuration SMD 2727 SMD 2727 SMD 3535 SMD 3535
Pixel Density 43,264 pixels/m²
 28,224 pixels/m²
 15,625 pixels/m²
 10,000 pixels/m²
Module Dimensions (W × H) (mm) 250 × 250 320 × 320 256 × 256 320 × 160
Panel Dimensions (mm) 1000 × 1000 × 187 1280 × 960 × 187 1280 × 960 × 187 1280 × 960 × 187
NO .of Modules Per Panel (W × H) 4 × 4 4 × 3 5 × 3 3× 6
Physical Resolution of Module (W × H) 52 × 52 48 × 48 32 × 32 32 × 16
Physical Resolution of Panel (W × H) 208 × 208 192 × 144 160 × 96 96 × 96
Panel Material Steel / Aluminum Steel / Aluminum Steel / Aluminum Steel / Aluminum
Weight 65/45 65/45 65/45 65/45
Processing 16 bit 16 bit 16 bit 16 bit
Colours 281 trillion 281 trillion 281 trillion 281 trillion
Contrast Ratio 2,000 : 1 2,000 : 1 2,000 : 1 2,000 : 1
Average Power Consumption 360 W/panel 360 W/panel 360 W/panel 360 W/panel
Max Power Consumption 900 W/panel 900 W/panel 900 W/panel 900 W/panel
Refresh Rate >1,920 Hz >1,920 Hz >1,920 Hz >1,920 Hz
Brightness ≥6500 nits ≥6500 nits ≥6500 nits ≥6500 nits
Horizontal Viewing Angle 160° 160° 160° 160°
Vertical Viewing angle 140° 140° 140° 140°
Expected Lifetime 100, 000 Hrs 100, 000 Hrs 100, 000 Hrs 100, 000 Hrs
Servicing Front / Rear Front / Rear Front / Rear Front / Rear
IP Rating (Front/Rear) IP 65/ IP 54 IP 65/ IP 54 IP 65/ IP 54 IP 65/ IP 54
Operating Temp/Humidity -20ºC - 50ºC / 10% - 90% -20ºC - 50ºC / 10% - 90% -20ºC - 50ºC / 10% - 90% -20ºC - 50ºC / 10% - 90%
Storage Temp/Humidity -20ºC - 50ºC / 10% - 90% -20ºC - 50ºC / 10% - 90% -20ºC - 50ºC / 10% - 90% -20ºC - 50ºC / 10% - 90%



Multifunctional Module Buckle
Special multifunctional module buckle designed for adjusting gaps between module and cabinet to ensure the smoothness and alignment.


Fast Installation and Easy Maintenance

Fast lock system design guarantees a quick and easy installation
Frone access


IP65 Fully Adapt to Outdoor Environment
Operating Temperature -20°c- 60°c
Operating Humidity -10% - 90%

Intelligent Software System
Intelligent control and player system by cloud technology
Time management and real time monitoring

Waterproof IP65 Front Service LED Display High Brightness Fast Lock Waterproof IP65 Front Service LED Display High Brightness Fast Lock

Why choose LED Display?

Waterproof IP65 Front Service LED Display High Brightness Fast Lock

Our Service

1. Pre-sale service:
Reply enquiries in 24 hours.
Market research and forecast for customer.
Provide unique and professional solutions based on customer's requirement
Data sheet and samples offer.
Other services, such as special packing design, factory visiting and so on.


2. In-sale service:
Tracking report in producing.
Quality test report for every order.
Photos and videos as per customer's requirement.
Free spare parts.


3. After-sale service:
Lifetime free maintenance and upgrade.
Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
Customer satisfaction tracking report.
Free technician training.
Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
Special service for big project, such as stadium, exhibitions, squares and so on.

Waterproof IP65 Front Service LED Display High Brightness Fast Lock

COMPANY INTRODUCTION

Shenzhen BAKO VISION Technology Co.,Ltd, started in Shenzhen in 2005, a world class manufacturer of technologically advanced LED displays, is SHENZHEN BAKO LTD holding end professional customers among domestic and overseas markets.
Do not be hesitate to contact us if you have any quiry!

Waterproof IP65 Front Service LED Display High Brightness Fast Lock

FAQ

Q1. Do you provide samples?is it free or extra?

A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

Q2. How to order?
A: Please send us your purchase order by Email or we can make you proforma invoice under your request.
We need to know the following information for your order before sending you PI.
1) Product information-Quantity,Specification(Size,Material,Technological if needed and Packing requirements etc.
2) Delivery time required.
3) Shipping information-Company name,Street address,Phone&Fax number,Destination sea port.
4) Forwarder's contact details if there's any in China.

Q3. Do you offer guarantee for the products?

A: Yes,we offer 2-5 years warranty to our products.
