Waterproof Stadium Perimeter Led Display With MBI5153 Driver IC Light Weight
Waterproof Stadium Perimeter Led Display With MBI5153 Driver IC Light Weight
Waterproof Stadium Perimeter Led Display With MBI5153 Driver IC Light Weight
Waterproof Stadium Perimeter Led Display With MBI5153 Driver IC Light Weight
Waterproof Stadium Perimeter Led Display With MBI5153 Driver IC Light Weight
Waterproof Stadium Perimeter Led Display With MBI5153 Driver IC Light Weight
Waterproof Stadium Perimeter Led Display With MBI5153 Driver IC Light Weight
Waterproof Stadium Perimeter Led Display With MBI5153 Driver IC Light Weight
Specifications
Brand Name :
bakovision
Model Number :
P10
Certification :
CE, Rohs, Fcc, ETL
Place of Origin :
China
MOQ :
1sqm
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
1000sqm, 20-25 days
Delivery Time :
20-25days
Packaging Details :
wooden box or flight case
Pixel Pitch :
10mm
driver IC :
MBI5153
Brightness :
1200nits
Refresh Rate :
2000Hz
Power supply :
Q-Energy
Cabinet material :
Aluminum
Description

Light Weight Sports Perimeter Led Display for Stadium Game, High Refresh Rate High Brightnes

Description:
1. High Brightness
More than 1500nits and it can be sawn from long distance.
2. Adjustable Support and Quick Rigging System
Flexible support design makes LED panel lean by multi angles to cater audience’s needs and quick rigging system design makes the installation and dismantle easier and faster.
3. Waterproof and 2 Year Warranty
Water Proof IP65 and 2 year warranty. LED display can work in all-weather condition very well.

Why choose BAKOVISION?
1. more than 10 years experience in led display industry, we have most talented engineers to design best products for our clients;
2. Top quality machines to make top quality products;
3. Most competitive price make our led displays are afordable;
4. For key business partners, we can offer financial credit;
5. We Use Top Rate LED to make best Led display screens, as well as best power supply, high quality signal & power cables, etc.
6. Strict Perfect anti-static precautions: during manufacturing, static electric damage is the most serious problem.
7. Use advanced processing technology, machinery guarantee for high-quality and long-life time products


Specifications

Parameter Unit Value
Pitch mm 10
Brightness nits 1,200
Viewing angle – Horizontal (50% brightness) deg. 140
Viewing angle – Vertical (50% brightness) deg. 140
Panel width mm 1,280
Panel height mm 800
Panel depth mm 136
Panel area sq. m. 1.024
Panel material Epoxy paint coated aluminum
Panel Mode Quick Assembly Cabinet with Bracket
Panel protection Soft mask
Ingress protection (front/rear) IP IP21/IP43
Operating temperature range deg. C -30 to +60
Humidity operating RH 10% ~ 90%
Resolution per panel 128×80
LED per sq. meter 10,000
Recommended minimum viewing distance m 6
Recommended best viewing distance m 10~40
Colors 281 Trillion
Grey scale (linear) Levels 65,536 levels per color
Brightness control Levels 100
Contrast ratio 1,000:1
Processing depth bit 16
Video frame rate Hertz 60
Display refresh rate Hertz 180~3,000
Input voltage (nominal) VAC 110 to 240
Input power frequency Hertz 50 to 60
Input power (max) Watts/ cabinet. 600
Input power (typical) Watts/ cabinet. 240
Multimedia data format DVI,MPG,AVI,WMV,RM etc.
Data interconnection UTP Cat 5/Optical Fiber
Mounting system Stand on ground by bracket
