P10 Basketball / Football Pitch Advertising Boards , Outdoor Programmable Led Signs
P10 Basketball / Football Pitch Advertising Boards , Outdoor Programmable Led Signs
P10 Basketball / Football Pitch Advertising Boards , Outdoor Programmable Led Signs
P10 Basketball / Football Pitch Advertising Boards , Outdoor Programmable Led Signs
P10 Basketball / Football Pitch Advertising Boards , Outdoor Programmable Led Signs
P10 Basketball / Football Pitch Advertising Boards , Outdoor Programmable Led Signs
Specifications
Brand Name :
Bakovision
Model Number :
P10
Certification :
CE, RoHS, ETL, FCC
Place of Origin :
China
MOQ :
1sqm
Price :
negotiable
Delivery Time :
20-25days
Packaging Details :
flight case or wooden box
Pitch :
6mm
Led Type :
SMD
Cabinet size :
1280x960
Brightness :
1000nits
IP rate :
IP43
Refresh rate :
1920Hz
Description

P10 Indoor Sports Perimeter LED Display For Basketball Club , Stadium Advertising Boards

Product Description

Main features of P10 indoor perimeter LED diaplsy basketball stadium advertising display
1. Claw lock system to link cabinets to avoid visible gaps between cabinets;
2. Soft rubber mask facia to protect the screen and the players on impact;
3. Aliminum cabinets with light weight;
4. Synchronous and asynchronous control system together, the most stable performance;
5. Simple power and data connections, daisy chain from one cabinet to the next for fast connection;
6. Any cabinet in any position, no need for numbering cabinets and ensuring they are connected in the correct order;
7. Easy software set-up when cabinets are connected;
8. Wide viewing angle, 140 degree both horizontal and vertical;
9. Customizable for various sizes;
10. Excellent after-sales service, warranty of three years;
11. CE, RoHS, ISO certificate

Parameter Unit Value
Pitch mm 6
Brightness nits 1,500
Color temperature deg. K 6,500
Viewing angle – Horizontal (50% brightness) deg. 140(-70 ~ +70)
Viewing angle – Vertical (50% brightness) deg. 140(-70 ~ +70)
Panel weight kg 37
Panel width mm 1,152
Panel height mm 960
Panel depth mm 134
Panel area sq. m. 1.106
Panel material Epoxy paint coated aluminum
Panel Mode Quick Assembly Cabinet with Bracket
Panel protection Soft mask
Ingress protection (front/rear) IP IP22/IP43
Operating temperature range deg. C -30 to +60
Humidity operating RH 10% ~ 90%
Pixel type and configuration R/G/B 3in1 SMD
Resolution per panel 192×160
Dot per panel 30,720
Dot per sq. meter 27,777
LED per sq. meter 27,777
Recommended minimum viewing distance m 4.56
Recommended best viewing distance m 6~60
Colors 281 Trillion
Grey scale (linear) Levels 65,536 levels per color
Brightness control Levels 100
Contrast ratio 1,000:1
Processing depth bit 16
Video frame rate Hertz 60
Display refresh rate Hertz 180~3,000
Input voltage (nominal) VAC 110 to 240
Input power frequency Hertz 50 to 60
Input power (max) Watts/ cabinet. 1,000
Input power (typical) Watts/ cabinet. 400
Lifetime (50% brightness) Hours ≥100,000
Red wavelength (dominant) nm 620~625
Green wavelength (dominant) nm 520~525
Blue wavelength (dominant) nm 470~475
Multimedia data format DVI,MPG,AVI,WMV,RM etc.
Data interconnection UTP Cat 5/Optical Fiber
Mounting system Stand on ground by bracket
