3840Hz P6 Indoor Sports Perimeter Led Display Panel for Basketball Volleyball Game
3840Hz P6 Indoor Sports Perimeter Led Display Panel for Basketball Volleyball Game
3840Hz P6 Indoor Sports Perimeter Led Display Panel for Basketball Volleyball Game
3840Hz P6 Indoor Sports Perimeter Led Display Panel for Basketball Volleyball Game
3840Hz P6 Indoor Sports Perimeter Led Display Panel for Basketball Volleyball Game
3840Hz P6 Indoor Sports Perimeter Led Display Panel for Basketball Volleyball Game
3840Hz P6 Indoor Sports Perimeter Led Display Panel for Basketball Volleyball Game
3840Hz P6 Indoor Sports Perimeter Led Display Panel for Basketball Volleyball Game
Specifications
Brand Name :
bakovision
Model Number :
P6
Certification :
CE, Rohs, Fcc, ETL
Place of Origin :
China
MOQ :
1sqm
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
1000sqm, 20-25 days
Delivery Time :
20-25days
Packaging Details :
wooden box or flight case
Cabinet size :
1152x960mm
driver IC :
MBI5124
Brightness :
1500nits
IP Rate :
IP43
Refresh Rate :
2000Hz
Working voltage :
110/220V
Description

3840Hz P6 Indoor Sports Perimeter Led Display Panel for Basketball Volleyball Game

Sports Perimeter Led Display Features:

1. We Use Top Rate LED to make best Led display screens, as well as best power supply, high quality signal & power cables, etc.

2. we can tailor our product according to our clients requirements;

3. Strict Perfect anti-static precautions: during manufacturing, static electric damage is the most serious problem.

4. Can be normally used under the temperature between -20 and +65 degree .

5. With production capacity of 8,000 m2 per month, we can make in-time delivery.

6. Use advanced processing technology, machinery guarantee for high-quality and long-life time products

Company Information

Business Type: Manufacturer

Main Product:

Outdoor Rental Led Display

Indoor Rental Led Display

Outdoor Fixed Led Display

Indoor Fixed Led Display

Stage Rental Led Display

HD Led Display

Billboard Led Display

Transparent Led Screens

Flexible Led Display

Front service Led Display

Led Curtain Display

Mobile Led Screen

Sports Perimeter Led Display

Establisgment: 2005 ( 13 years )

Management System Certification: CE

Service: ODM OEM

Sports Perimeter Led Display Specs:

Parameter Value Unit
Pitch 6 mm
Brightness 1,500 nits
Viewing angle – Horizontal (50% brightness) 140(-70 ~ +70) deg.
Viewing angle – Vertical (50% brightness) 140(-70 ~ +70) deg.
Panel weight 37 kg
Panel width 1,152 mm
Panel height 960 mm
Panel area 1.106 sq. m.
Panel material Epoxy paint coated aluminum
Panel Mode Quick Assembly Cabinet with Bracket
Panel protection Soft mask
Ingress protection (front/rear) IP22/IP43 IP
Operating temperature range -30 to +60 deg. C
Humidity operating 10% ~ 90% RH
Pixel type and configuration 3in1 SMD R/G/B
Resolution per panel 192×160
Recommended minimum viewing distance 4.56 m
Recommended best viewing distance 6~60 m
Colors 281 Trillion
Grey scale (linear) 65,536 levels per color Levels
Brightness control 100 Levels
Contrast ratio 1,000:1
Processing depth 16 bit
Video frame rate 60 Hz
Display refresh rate 2000 Hz
Input voltage (nominal) 110 to 240 VAC
Input power frequency 50 to 60 Hertz
Power consumption (max) 1,000 Watts/ cabinet.
Power consumption(av) 400 Watts/ cabinet.
