ONN M4F-USB Signal Light Tower 5V Beacon with Buzzer Plug & Play. Loud Alerts for Machine Status. Perfect for Factory Automation.

Product Overview

Φ60 modular stack tower light powered by DC5V USB, IP40 dustproof rating. Black/grey ABS housing with aluminum support pole, available in 1–5 color layers (R/Y/G/B/W). Controlled via USB serial communication with hexadecimal command codes; independently adjustable light color, dual-volume buzzer and four flash speeds. Three mounting structures (foldable base / pole plate / L bracket), CE certified, 50,000-hour LED lifespan, 18-month warranty for CNC and automated production equipment.

Quick Detail

• Housing: Black/grey ABS + aluminum pole, Φ60 PC round lens, IP40 dustproof
• Power Supply: DC5V USB input, current 60–260mA, single color 1.5W, total power ≤6.3W
• Light Source: 0.12W 2835 SMD LED, 360° omnidirectional viewing angle
• Color Options: Red / Yellow / Green / Blue / White, customizable multi-layer combinations
• Buzzer: Max 90dB, low & high two volume levels serial-controllable
• Flash Modes: 4 adjustable flash cycles (0.85s / 1.7s / 2.5s / flash off)
• Communication: USB serial port, baud rate 9600, fixed frame header 0xFF & tail 0xAA
• Mount Types: Foldable base / pole plate / L-type metal bracket
• Standard Cable: 0.5m USB wire
• Environment: Operate -20~45℃, store -40~70℃, humidity 10%–90%
• Lifespan: 50,000H, CE certified

Specifications

Competitive Advantages

• USB DC5V low-voltage power supply, directly connect to PC for serial control without extra power adapter
• Full serial customization: 5 optional light colors, dual buzzer volume, 4 adjustable flash speeds
• Three universal mounting structures fit different machine panel & cabinet installation demands
• Excellent heat dissipation design and high-quality components guarantee long service life
• Multi-layer multi-color collocation to distinguish complex equipment running, warning and fault signals
• Compact streamline appearance with customizable brand LOGO, high cost performance

Applications

CNC machining centers, SMT lines, automated packaging, injection molding, robotics workcells, conveyors, and industrial warning systems.

Package Info

12 pieces per outer carton for all types, single net weight ranges 0.3–0.45kg
