Specifications
Supply Ability :
1-800pcs 5-12 working days
Power :
DC12V/24V AC 220V
MOQ :
1
Payment Terms :
T/T
Warranty(Year) :
2-Year
Brand Name :
ONN
Model Number :
X3Q
Application :
Freezer Shelf, supermarket shelves
Price :
$4.8-$8
Place of Origin :
Guangdong, China
Packaging Details :
packaging size based on the length
Installation :
Clip or magnet
Certification :
CE
IP Rating :
IP65
Delivery Time :
5-8 working days
Color Temperature(CCT) :
2800-3200K;4000-4500K;6000-6500K
Description

ONN-X3Q High Brightness LED Cooler Light IP65 for Supermarket Cold Rooms

Product Overview

The ONN-X3Q is a vapor-sealed LED freezer light engineered for cold storage environments including walk-in coolers, refrigerated displays, and supermarket freezers. Featuring high-brightness SMD2835 LED chips with 95-100lm/W efficacy, it delivers cool white illumination (5500-6000K) with excellent color rendering (CRI>80). The IP65-rated slim body is fully sealed against moisture, steam, and water droplets—ensuring reliable operation in high-humidity conditions. Available in 9 lengths from 315mm to 1435mm with left or right 45° emitting options. 40,000-hour lifespan. CE/RoHS compliant. 2-year warranty.

Quick Detail

  • Vapor Sealed: IP65 waterproof, fully sealed against moisture and steam

  • High Efficiency: SMD2835 LEDs, 95-100lm/W, CRI>80, 5500-6000K

  • 9 Lengths: 315/490/575/740/875/1025/1175/1435mm (custom available)

  • Emitting Direction: Left 45° or Right 45° optional

  • Slim Design: Only 22.5mm width, space-saving profile

  • Voltage: AC200-240V 50/60Hz | Driver: Non-isolated, PF>0.9

  • Lifetime: 40,000 hours | Warranty: 2 years

Specifications

Parameter Specification
Model ONN-X3Q
IP Rating IP65
LED Type SMD2835
Luminous Efficacy 95-100 lm/W
CRI >80Ra
CCT 5500-6000K
Emitting Angle 110°-120°
Voltage AC200-240V (50/60Hz)
Power Factor >0.9
Surface Temp <50°C
Lifetime 40,000 hours
Working Temp -20~45°C

Power by Length

Length (mm) 315 490 575 740 875 1025 1175 1435
Power 8W 11W 12W 16W 18W 20W 24W 30W

Applications

Walk-in coolers, refrigerated display cases, freezer rooms, supermarket shelves, store counters, cold storage warehouses.

Package Info

Length (mm) 343 518 603 768 901 1055 1203 1463 1748
Qty/Carton 200 100 100 100 100 100 100 100 200
G.W. (kg) 9.6 7.7 7.5 8.5 9.3 10.2 11 12.6 14.7
