Octagon VA LCD Display with 6 O'clock Viewing Angle 4.8V Working Voltage and 1/4 Duty 1/3 Bias
Octagon VA LCD Display with 6 O'clock Viewing Angle 4.8V Working Voltage and 1/4 Duty 1/3 Bias
Octagon VA LCD Display with 6 O'clock Viewing Angle 4.8V Working Voltage and 1/4 Duty 1/3 Bias
Octagon VA LCD Display with 6 O'clock Viewing Angle 4.8V Working Voltage and 1/4 Duty 1/3 Bias
Specifications
Display mode :
VA Negative
View Angle Direction :
6O′clock
Working voltage :
4.8V
Polarizer Mode :
Transflective Transmissive (Customized)
Drive Condition :
1/4 Duty1/3bias
Operating Temperature :
0~+50℃
Backlight :
White
Connector :
PIN, 19 numbers
Place of Origin :
China
Brand Name :
BBI
Certification :
ISO9001 RoHS
MOQ :
1000
Price :
0.7-7USD
Packaging Details :
CARTON
Delivery Time :
3-4WEEKS
Payment Terms :
T/T
Supply Ability :
100000/MONTH
Description
Octagon VA LCD Display Black Background 2 Digit 7 Segment Display
Octagonal VA liquid crystal display with black background and 2-digit 7-segment display is a special type of liquid crystal display device, featuring an octagonal appearance, VA liquid crystal technology, black background, and 2-digit 7-segment display.
Key Features
  • Octagonal design: Unique visual effect suitable for special applications
  • VA technology: High contrast ratio and wide viewing angle
  • Black background: Enhances visibility and reduces glare
  • 2-digit 7-segment display: Shows numbers 0-9 and simple characters
Technical Specifications
LCD Type VA, Negative
Viewing Angle 6 O'clock
Operating Temperature 0~+50℃
Voltage 4.8V
Backlight White
Detailed Parameters
Outline Dimension 35.64(W)* 37.64(H)* 2.8(T) mm Display mode VA, Negative
LCD viewing area 33.64(W)* 33.64(H) mm Polarizer type Transmissive
Driver IC / LED backlight White
Drive method 1/4 Duty, 1/3 Bias Working voltage 4.8V
Viewing angle 6 O'clock Connection Way PIN, 19 numbers
Operate temperature 0℃~+50℃ Storage temperature -10~+60℃
LCD Technology Comparison
  • TN (Twisted Nematic): Basic, low-cost with limited viewing angles
  • VA (Vertical Alignment): High contrast and better viewing angles (used in this product)
  • STN (Super Twisted Nematic): Improved contrast for larger displays
Octagon VA LCD Display with 6 O'clock Viewing Angle 4.8V Working Voltage and 1/4 Duty 1/3 Bias Octagon VA LCD Display with 6 O'clock Viewing Angle 4.8V Working Voltage and 1/4 Duty 1/3 Bias


Applications
Ideal for motorcycle dashboards, smart home appliances, and other devices requiring special appearance designs with clear numeric displays.
