P0650VGF1MA00 Tianma 6.5 Inch Led Backlit TFT LCD Colour Monitor Module 1200cd/M²
P0650VGF1MA00 Tianma 6.5 Inch Led Backlit TFT LCD Colour Monitor Module 1200cd/M²
P0650VGF1MA00 Tianma 6.5 Inch Led Backlit TFT LCD Colour Monitor Module 1200cd/M²
P0650VGF1MA00 Tianma 6.5 Inch Led Backlit TFT LCD Colour Monitor Module 1200cd/M²
P0650VGF1MA00 Tianma 6.5 Inch Led Backlit TFT LCD Colour Monitor Module 1200cd/M²
P0650VGF1MA00 Tianma 6.5 Inch Led Backlit TFT LCD Colour Monitor Module 1200cd/M²
P0650VGF1MA00 Tianma 6.5 Inch Led Backlit TFT LCD Colour Monitor Module 1200cd/M²
P0650VGF1MA00 Tianma 6.5 Inch Led Backlit TFT LCD Colour Monitor Module 1200cd/M²
P0650VGF1MA00 Tianma 6.5 Inch Led Backlit TFT LCD Colour Monitor Module 1200cd/M²
P0650VGF1MA00 Tianma 6.5 Inch Led Backlit TFT LCD Colour Monitor Module 1200cd/M²
P0650VGF1MA00 Tianma 6.5 Inch Led Backlit TFT LCD Colour Monitor Module 1200cd/M²
P0650VGF1MA00 Tianma 6.5 Inch Led Backlit TFT LCD Colour Monitor Module 1200cd/M²
Specifications
Brand Name :
Tianma
Model Number :
P0650VGF1MA00
Place of Origin :
China
MOQ :
1
Price :
$98/pieces 1-99 pieces
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Delivery Time :
3-5 working days
Packaging Details :
40pcs/Box
Panel Type :
a-Si TFT-LCD, LCM
Display Size :
6.5 inch
Supplier Type :
Original Brand
Resolution :
640(RGB)×480, VGA 122PPI
Module Outsize(mm) :
154(W)×121(H) ×11(D) mm
Viewing Angle :
88/88/88/88 (Typ.)(CR≥10)
Display Color :
262K/16.7M 97% sRGB
Brightness :
1200 cd/m² (Typ.)
Contrast Ratio :
900:1 (Typ.) (TM)
Signal Interface :
LVDS (1 ch, 6/8-bit) , 20 pins Connector
Touch panel :
Without
Lamp Type :
6S2P WLED , 100K hours , Without Driver
Environment :
Operating : -30 ~ 80 °C Storage: -40 ~ 90 °C Vibration 6.8G
Application :
Industrial Equipment Automotive Outdoor High Brightness
Warranty :
12months
Description
Tianma P0650VGF1MA00 6.5 inch TFT-LCD Module with 1200 cd/m² Brightness and Wide Temperature Range for Automotive and Industrial Displays
High-brightness 6.5-inch automotive display screen engineered for demanding industrial applications requiring reliable operation across wide temperature ranges. Features 640*480 VGA resolution with LVDS interface and exceptional 1200 cd/m² brightness for superior visibility in bright environments.
Key Features
  • 640*480 VGA resolution with 122 PPI for sharp display clarity
  • 1200 cd/m² ultra-high brightness for excellent outdoor visibility
  • SFT technology with 88/88/88/88 viewing angles (CR≥10)
  • LVDS interface with 20-pin FPC connector
  • 900:1 contrast ratio for superior image quality
  • WLED backlight with 100,000 hours lifespan
  • 16.7M color support with 97% sRGB color gamut
  • Wide operating temperature range: -30°C to 80°C
Technical Specifications
Panel Model P0650VGF1MA00 Panel Brand Tianma
Size 6.5 inch Panel Type a-Si TFT-LCD, LCM
Resolution 640(RGB)*480, VGA 122PPI Pixel Format RGB Vertical Stripe
Module Dimensions 154(W)*121(H)*11(D) mm Display Mode SFT, Normally Black, Transmissive
Active Area 132.48(W)*99.36(H) mm Response Time 30 ms (Typ.)
Display Colors 262K/16.7M 97% sRGB Light Source WLED [6S2P], 100K hours, W/O Driver
Viewing Angle 88/88/88/88 (Typ.)(CR≥10) Touch Without
Brightness 1200 cd/m² (Typ.) Power Supply 3.3V
Contrast Ratio 900:1 (Typ.) Application Industrial, Automotive, Outdoor
Frame Rate 60Hz Storage Temperature -40°C to 90°C
Interface Type LVDS (1 ch, 6/8-bit), 20 pins Connector Operating Temperature -30°C to 80°C
FPC Connector JAE, FI-SE20P-HFE, Pitch 1.25mm Weight 179g (Typ.)
Applications
Industrial equipment and machinery Automation equipment displays Outdoor high brightness applications CNC machine displays Medical equipment EV Charger Display Industrial Control Display
Customization Options
Available with optional cover glass using Corning Gorilla GG3 or Asahi Nitrate materials in various thicknesses. Surface treatments include AR (Anti-Reflective), AF (Anti-Fingerprint), and AG (Anti-Glare). This display can be equipped with an HDMI driver board for easier debugging and evaluation, as well as for direct integration into your products. Optional industrial-grade capacitive touch available.
About Wan Display
Founded in 2019, Shenzhen Wanshujie Photoelectric Technology specializes in providing original screens from various brands and offers comprehensive touchscreen integration solutions. We focus on differentiated products and provide personalized customization services. With extensive industry experience and superior supply chain resources, we deliver fast, first-tier services to our clients.
