Specifications
Place of Origin :
China
MOQ :
2pcs
Price :
$10/pieces 1-99 pieces
Brand Name :
WANSHUJIE
Description

5.0-inch 800*480 Transflective TFT LCD Screen Industrial TFT Display with RGB Interface

1. Module Name: 5.0-inch 800*480 transflective TFT LCD with HX8264+HX8664, 16/18/24-bit RGB interface
2. Model:
3. Compatible Models:
4. Size: 5.0 inches
5. Touch Panel: No
6. Display Mode: Transflective
7. Display Colors: 65K/262K/16.7M
8. Resolution: 800*480
9. Dot Pitch: 0.135(H)*0.135(V)
10. Viewing Direction: 6 o'clock
11. Controller IC: HX8264+HX8664
12. Display Type: Transflective, Normally White
13. Outline Dimension: 120.7*75.9*2.95mm
14. Viewing Area: 108.0*64.8mm
15. Active Area: 108.0*64.8mm
16. Brightness: 280cd/m²
17. Contrast Ratio: 35
18. Interface Type: 16/18/24-bit RGB
19. Pin Count: 40
20. Pin Pitch: 0.5mm
21. Connection Type: Plug-in
22. Operating Voltage: 3.3V
23. Backlight Color & Type: White LED Backlight
24. Backlight Circuit: 12 LEDs, 2 parallel groups × 6 series
Vled =16.8-19.6V, Iled=40mA
25. Service Life: 50000h
26. Operating Temperature: -20~70°C
27. Storage Temperature: -30~80°C
28. Quality System Certifications: ISO9001, ISO13485, TS16949
29. Product Certification: RoHS
