Specifications
Brand Name :
Zaozhuang NO.1
Model Number :
X6036B
Certification :
CE,ISO
Place of Origin :
Shandong, China
MOQ :
1 set
Price :
6000USD
Payment Terms :
T/T
Supply Ability :
1000 sets/month
Delivery Time :
15 days after getting the deposit.
Packaging Details :
Export standard wooden case or as customers' requirement
Working desk size :
1500x360mm
Number of T-slots :
3
Workbench trip :
1000X360X400mm
Spindle speed range :
60-1800(12 steps)
Dimensions :
2220x1790x1980mm
Machine weight :
2400/2500kg
Description

X6036B China High Performance Universal Lift Table Milling Machine with Super Low Price

The universal lifting platform milling machine is a general-purpose metal cutting machine tool. This machine tool has a rigid structure, can bear heavy loads for cutting, and is suitable for machining various small planes, inclined surfaces, grooves, holes, and other gear parts.


Standard configuration:

1.X/Y axis automatic.

2.Ecectric lift of Z axis.


Optional configuration:

1.Vertical milling head.

2.Three-axis digital display.

3.Electronic oil pump.

4.Universial dividing head.

5.Custom tool holder.


Machine tool accessories:

1.Milling Chuck.

2.7:24 middle set.

3.Horizontal milling arbor assembly.

4.Allen wrench.

5.Single-head spanner.

6.Pull Rod Assembly.

7.Anchor bolts.

8.Double-head socket wrench.


Product specification:

PARAMETER ITEM
UNIT
 X6036B
Working desk size mm 1500x360
Number of T-slots -- 3
Workbench trip mm 1000/360/400
Spindle hole taper -- 7:24/ISO50
Spindle speed range rpm 60-1800(12 steps)
Worktable feed speed mm/min 15-370 (8 steps)
Workbench down stroke mm 500
Worktable vertical lifting speed mm/min 560
Motor Power kw 4
Dimensions mm 2220x1790x1980
Machine weight kg 2400/2500
Vertical shaft end to table distance mm 50-550
Spindle center to vertical rail surface distance mm 320


Details Display:

X6036B China High Performance Universal Lift Table Milling Machine with Super Low Price


X6036B China High Performance Universal Lift Table Milling Machine with Super Low Price


X6036B China High Performance Universal Lift Table Milling Machine with Super Low Price


X6036B China High Performance Universal Lift Table Milling Machine with Super Low Price
