Fully Automatic Closed Flash Point Testing Equipment Atmospheric Pressure Calibration
Fully Automatic Closed Flash Point Testing Equipment Atmospheric Pressure Calibration
Fully Automatic Closed Flash Point Testing Equipment Atmospheric Pressure Calibration
Fully Automatic Closed Flash Point Testing Equipment Atmospheric Pressure Calibration
Specifications
Brand Name :
Shengtai Instrument
Model Number :
SK107
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
100000sets/year
Delivery Time :
7-15work-days
Packaging Details :
wooden case;Packaging size: 345 ×405× 525mm ;Packaging weight: 19kg
Display :
large screen full Chinese LCD module display
Measurement range :
room temperature~390 ℃
Accuracy :
≥ 104 ℃± 2 ℃ ≤ 104 ℃± 1 ℃
Executive standard :
GB261-83 ISO-2719
Cooling mode :
forced air cooling
Repeatability :
flash point ≤ 104℃, error ± 2 ℃; Flash point ≥ 104 ℃ Error ± 4 ℃
Heating speed :
Step A: Heating rate: 5 ~ 6℃/min
Power supply :
AC 220V ± 22V 50Hz ± 2.5Hz
Power :
100VA
Operating ambient temperature :
10 ℃~35 ℃
Operating ambient humidity :
≤ 85%
Overall dimension :
410X260X300mm Weight:15kg
Description

SK107 fully automatic closed flash point tester, domestically produced sensor, atmospheric pressure calibration

Fully Automatic Closed Flash Point Testing Equipment Atmospheric Pressure Calibration

SK107 is a fully automatic closed-cup flash point tester, which is developed by centralized surgery. The instrument adopts microcomputer technology and large-screen LCD display. The instrument is heated up, automatically raised and lowered, automatically ventilated, and automatically ignited according to the standard method, without air source, automatic display, automatic locking of flash point value, and automatic printing of results. After the test, it can automatically cool down and realize the full automation of the working process. It has the advantages of accurate measurement, good repeatability, stable performance and simple operation. It is widely used in power, petroleum, chemical, commodity inspection, scientific research and other departments. Comply with ISO-2719 and GB261-83 standards.

Technical parameter

Display large screen full Chinese LCD module display.
Measurement range room temperature~390 ℃
Accuracy ≥ 104 ℃± 2 ℃ ≤ 104 ℃± 1 ℃
Executive standard GB261-83 ISO-2719
Cooling mode forced air cooling
Repeatability flash point ≤ 104℃, error ± 2 ℃
Flash point ≥ 104 ℃ Error ± 4 ℃
Heating speed Step A: Heating rate: 5 ~ 6℃/min
Power supply AC 220V ± 22V 50Hz ± 2.5Hz
Power 100VA
Operating ambient temperature 10 ℃~35 ℃
Operating ambient humidity ≤ 85%
Overall dimension:410X260X300mm Weight:15kg
Packaging size: 345 ×405× 525mm Packaging weight: 19kg

Packing List

S/N Name Quantity Unit Remarks
1 Automatic closing flash point meter 1 set
2 Oil cup 1 piece
3 AC power cord 1 piece
4 Printing paper 1 piece
5 Operating instruction 1 piece
6 packing list 1 copy
7 Certificate of factory 1 copy
