Specifications
Type :
Testing Machine
Accuracy Class :
High Accuracy
Accuracy :
----
Brand Name :
LONROY
Place of Origin :
Guangdong, China
Application :
Auto Testing, Laboratory Testing, Lab Testing
customized support :
OEM, ODM, OBM
power :
1500 W
Protection Class :
Ip56
Voltage :
380 V
warranty :
1 Year
Production Capacity :
Approx. 0.25-0.5 kg
Dimensions :
1.2 m * 0.8 m * 1.6 m
Power Supply :
220/3*380V AC 50/60Hz
Total Power :
1500 W
MOQ :
1
Description

Cotton Fancy Yarn Spinning Machine Laboratory Fancy Cotton Spinning Frame Small-scale Spinning Machine

Product Description

Application Scope

This equipment is equipped with a core yarn roller, and the front, middle, and rear rollers are independently driven. With two sets of roving feeding, it can produce fancy yarns with varying colors and structures by changing the drafting ratio and yarn twist.

Features

This machine is one of the small-scale spinning machines in the series. It has a small footprint, simple operation and adjustment, and is suitable for rapid spinning trials with small amounts of raw materials. It is ideal for schools, research institutions, and R&D centers.

Cotton Fancy Yarn Spinning Machine Laboratory Fancy Cotton Spinning Frame Small-scale Spinning Machine

Technical Specification

Control Method

Touch screen + PLC

Number of Spindles

4/6

Twist Range

Approx. 200-2000 twists/m

Drafting Range

Approx. 2-50

Fiber Length

22 to 42 mm

Production Capacity

Approx. 0.25-0.5 kg

Ring Spindle Speed

12000 rpm

Roller Size

Φ25/25/25 mm

Ring Size

Φ42 mm

Total Power

1500 W

Voltage

220/3*380V AC 50/60Hz

Dimensions

1.2 m * 0.8 m * 1.6 m

Cotton Fancy Yarn Spinning Machine Laboratory Fancy Cotton Spinning Frame Small-scale Spinning MachineCotton Fancy Yarn Spinning Machine Laboratory Fancy Cotton Spinning Frame Small-scale Spinning MachineCotton Fancy Yarn Spinning Machine Laboratory Fancy Cotton Spinning Frame Small-scale Spinning MachineCotton Fancy Yarn Spinning Machine Laboratory Fancy Cotton Spinning Frame Small-scale Spinning Machine
