Vertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing Equipment
Vertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing Equipment
Vertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing Equipment
Vertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing Equipment
Vertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing Equipment
Vertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing Equipment
Vertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing Equipment
Vertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing Equipment
Vertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing Equipment
Vertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing Equipment
Vertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing Equipment
Vertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing Equipment
Specifications
Type :
Testing Machine
Accuracy Class :
High Accuracy
Accuracy :
----
Brand Name :
LONROY
Place of Origin :
Guangdong, China
Application :
Auto Testing, Laboratory Testing, Lab Testing
customized support :
OEM, ODM, OBM
power :
---
Protection Class :
Ip56
Voltage :
220V Electrical Equipment
warranty :
1 Year
Model Number :
LR-FZ117
Dimensions (Vertical) :
Front 890mm * Side 630mm * Height 1300mm
Weight :
Approximately 90kg (subject to actual weight)
Power Supply :
Rated power 220V, frequency 50Hz
MOQ :
1
Description

Vertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing Equipment

Product Description

Product Application

This small rolling machine is suitable for dyeing samples of pure cotton, TC polyester-cotton, and other chemical fiber fabrics.

Vertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing Equipment

Technical Specification

Material

The entire machine is made of high-quality mirror-finish SUS304 stainless steel plate, with a reasonable structure, beautiful appearance, and durability.

Rollers

Roller material: High-precision nitrile rubber;

Cylinder

Large-section diaphragm cylinders on both sides, strong resistance to guide rail friction, automatic reset upon power failure.

Operation

Powered by compressed air, pressure is controlled by a pressure regulating valve. The rollers are driven by large-section diaphragm cylinders, maintaining consistent pressure on both sides, effectively mimicking the production process and ensuring the sample process meets production requirements.

Speed Adjustment

Variable frequency speed control: 0-18 rpm, speed can be adjusted arbitrarily. Voltage input 220V, 50Hz.

Safety Protection System

Panel emergency stop switch, knee-operated emergency stop switch, automatic reset upon power failure, providing comprehensive protection during use.

Valve & Gauge

Pressure regulating valve, solenoid valve, and embedded pressure gauge design, resulting in a clean and aesthetically pleasing appearance and reduced risk of damage.

Flushing System

Flushing system for convenient cleaning of the equipment before and after dyeing.

Air Gun

Handwheel-operated air gun, flexible to use and comfortable to handle.

Ergonomic Design

The equipment height is designed for easy operation, and the width is moderate, ensuring stability and saving space.

Dimensions (Vertical)

Front 890mm × Side 630mm × Height 1300mm

Weight

Approximately 90kg (subject to actual weight)

Note

Other sizes and specifications can be customized according to customer requirements.

Vertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing EquipmentVertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing EquipmentVertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing EquipmentVertical Pneumatic Electric Small Padder Automatic Rolling Machine Samples Dyeing Equipment
