Specifications
Type :
Testing Machine
Accuracy Class :
High Accuracy
Accuracy :
----
Brand Name :
LONROY
Place of Origin :
Guangdong, China
Application :
Auto Testing, Laboratory Testing, Lab Testing
customized support :
OEM, ODM, OBM
power :
1.5 kW
Protection Class :
Ip56
Voltage :
380 V
warranty :
1 Year
Motor power :
1.5 kW
Machine dimensions :
1200*1000*960 mm
Machine Weight :
1600 kg
Power supply :
Three-phase 380 V, 1.5 kW
MOQ :
1
Description

Rebar Bending Testing Machine Steel Bars Forward and Reverse Planar Bending Tester Steel Bar Bending Test Equipment

Product Description

Product Description

The rebar bending testing machine is a specialized equipment for performing forward and reverse planar bending tests on steel bars. The technical parameters and specifications of this equipment comply with the relevant provisions of GB/T1499.2-2007 "Steel for Reinforced Concrete - Part 2: Hot-rolled Ribbed Steel Bars" and YB/T5126-2003 "Test Methods for Bending and Reverse Bending of Steel Bars for Reinforced Concrete". It is widely used in metallurgy, machinery manufacturing, construction, engineering supervision, and technical quality supervision units.

This product features significant improvements in accessory matching, safety limit switches, replacement of wear parts, and extending the overall service life of the machine.

WRebar Bending Testing Machine Steel Bars Forward and Reverse Planar Bending Tester Steel Bar Bending Test Equipment

Technical Specification

Rebar bending diameter range

Φ6–40 mm

Forward bending angle

0°–180° (arbitrarily set)

Reverse bending angle

0°–25° (arbitrarily set)

Working disc rotation speed

≤3.7 r/min

Roller center distance

165 mm

Working disc diameter

Φ580 mm

Motor power

1.5 kW

Standard bending die set

Included

Machine dimensions

1200×1000×960 mm

Machine weight

1600 kg

Power supply

Three-phase 380 V, 1.5 kW

Rebar Bending Testing Machine Steel Bars Forward and Reverse Planar Bending Tester Steel Bar Bending Test EquipmentRebar Bending Testing Machine Steel Bars Forward and Reverse Planar Bending Tester Steel Bar Bending Test EquipmentRebar Bending Testing Machine Steel Bars Forward and Reverse Planar Bending Tester Steel Bar Bending Test EquipmentRebar Bending Testing Machine Steel Bars Forward and Reverse Planar Bending Tester Steel Bar Bending Test Equipment
