UP-3014 ISO179-2000 Standard Impact Testing Machine with Carbon Fiber Lever and Digital Encoder for Plastic and Rubber
UP-3014 ISO179-2000 Standard Impact Testing Machine with Carbon Fiber Lever and Digital Encoder for Plastic and Rubber
UP-3014 ISO179-2000 Standard Impact Testing Machine with Carbon Fiber Lever and Digital Encoder for Plastic and Rubber
UP-3014 ISO179-2000 Standard Impact Testing Machine with Carbon Fiber Lever and Digital Encoder for Plastic and Rubber
UP-3014 ISO179-2000 Standard Impact Testing Machine with Carbon Fiber Lever and Digital Encoder for Plastic and Rubber
UP-3014 ISO179-2000 Standard Impact Testing Machine with Carbon Fiber Lever and Digital Encoder for Plastic and Rubber
Specifications
MOQ :
1
Price :
Negotiable
Brand Name :
YOUBI
Model Number :
UP-3014
Certification :
CE,ISO
Place of Origin :
CHINA
Supply Ability :
80 Unit/Month
Delivery Time :
5-7 work days
Packaging Details :
Professional Export Packing
Model NO. :
UP-3014
Pendulum energy :
1J, 2.75J, 5.5J
Pendulum angle :
150°
Blade angle :
30°
Impact speed :
3.5m/s
Impact center distance :
335mm
Power supply :
AC220V±10% 50HZ
Applications :
Plastic,Rubber
Description

ISO179 Plastics - Hard Materials IZOD Impact Strength Test Machine

UP-3014 ISO179-2000 Standard Impact Testing Machine with Carbon Fiber Lever and Digital Encoder for Plastic and Rubber
UP-3014 ISO179-2000 Standard Impact Testing Machine with Carbon Fiber Lever and Digital Encoder for Plastic and Rubber
Product Description:
This kind of digital charpy impact tester is mainly used to measure the impact toughness of rigid plastic, reinforced nylon, fiberglass, ceramics, cast stone, insulation materials and other non-metallic materials.
It is the ideal testing equipment in the chemical industry, scientific research institutes, universities and quality testing departments.

Performance standards:
ISO179-2000 Determination of Plastics - Hard Materials Charpy Impact Strength
GB/T1043-2008 Rigid Plastic Charpy Impact Test Method
JB/T8762-1998 Plastics Charpy Impact Testing Machine
GB/T 18743-2002 Charpy Impact Test Method for Fluid Transport Via Thermoplastic Pipe (Suitable for pipe pieces)

Product Characteristic:
A. High-precision intelligent controller equipped with LCD display which you can read the data intuitively and accurately;
B. China's first carbon fiber lever (It has been patented); it succeeds in doing experiments without shaking involving the impact direction, improving the rigidity of materials, and concentrating impacting strength on the centroid of the pendulum, and using life increases.
C. Imported high-resolution digital encoders, higher and more stable angle measurement accuracy;
D. Aerodynamic impact hammer and imported ball bearings greatly reduce mechanical friction losses
E.Automatic calculation of the final result, 12 sets of the test data can be stored and averaged;
F. Optional interface of Chinese and English; units ( J / m, KJ / m2, kg-cm / cm, ft-ib / in )can be customized according to customers' requirements.
G. Built-in mini printer to print the test data

Specifications:
Item Charpy Impact Izod Impact
Pendulum energy 1J, 2J, 4J, 5J 1J, 2.75J, 5.5J
Pendulum angle 150°
Blade angle 30°
Blade front angle 5°
Blade back angle 10°
Impact speed 2.9m/s 3.5m/s
Impact center distance 221mm 335mm
Blade filleted radius R=2mm±0.5mm R=0.8mm±0.2mm

Energy loss		 0.5J ≤4.0J
1.0J ≤2.0J
2.0J ≤1.0J
≥4.0J≤0.5J		 2.75J ≤0.06J
5.5J ≤0.12J

Pendulum torque		 Pd1J=0.53590Nm
Pd2J=1.07180Nm Pd4J=2.14359Nm Pd5J=2.67949Nm 		Pd2.75J=1.47372Nm
Pd5.5J=2.94744Nm
Print out Capacity. Angle, energy, etc.
Power supply AC220V±10% 50HZ

UP-3014 ISO179-2000 Standard Impact Testing Machine with Carbon Fiber Lever and Digital Encoder for Plastic and Rubber
UP-3014 ISO179-2000 Standard Impact Testing Machine with Carbon Fiber Lever and Digital Encoder for Plastic and Rubber
UP-3014 ISO179-2000 Standard Impact Testing Machine with Carbon Fiber Lever and Digital Encoder for Plastic and Rubber
UP-3014 ISO179-2000 Standard Impact Testing Machine with Carbon Fiber Lever and Digital Encoder for Plastic and Rubber
UP-3014 ISO179-2000 Standard Impact Testing Machine with Carbon Fiber Lever and Digital Encoder for Plastic and RubberUP-3014 ISO179-2000 Standard Impact Testing Machine with Carbon Fiber Lever and Digital Encoder for Plastic and Rubber
Our service:
During the whole business process, we offer a Consultative Selling services.
1)Customer inquiry process:
Discussing testing requirements and technical details, suggested suitable products to customer to confirm.
Then quote the most suitable price according to customer requirements.

2)Specifications customize process:
Drawing related drawings to confirm with customer for customized requirements. Offer reference photos to show the appearance of the product. Then, confirm the final solution and confirm the final price with the customer.

3)Production and delivery process:
We will produce the machines according to confirmed PO requirements. Offering photos to show the production process.
After finishing production, offer photos to the customer to confirm again with the machine. Then do your own factory calibration or third-party calibration(as per customer requirements). Check and test all the details and then arrange packing.
Delivering the products is confirmed shipping time and informed the customer.

4)Installation and after-sale service:
Defines installing those products in the field and providing after-sales support.

FAQ:
1. Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?
Yes, we are the one of professional manufacturers of Environmental Chambers, Leather shoe testing equipment, and Plastic Rubber testing Equipment... in China. Every machine purchased from our factory has 12 month warranty after shipment. Generally, we offer 12 months for FREE maintenance. while considering sea transportation, we can extend 2 months for our customers.
Moreover, If your machine doesn't work, you can send us an e-mail or call us we will try our best to find the problem through our conversation or by video chat if necessary. Once we have confirmed the problem, the solution will be offered within 24 to 48 hours.
2. What about the delivery term?
For our standard machine which means normal machines, If we have stock in the warehouse, is 3-7 working days;
If there is no stock, normally, the delivery time is 15-20 working days after payment is received;
If you are in urgent need, we will make a special arrangement for you.
3. Do you accept customization services? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines but also customized machines according to your requirements. And we can also put your logo on the machine which means we offer OEM and ODM service.
4. How can I install and use the machine?
Once you have ordered the testing machines from us, we will send you the operation manual or video in English version through Email.
Most of our machine is shipped with a whole part, which means it is already installed, you just need to connect the power cable and start to use it. And if it's necessary, we can also assist you to install your machine on-site.
