UP-3012 IK Code High Energy Pendulum Impact Tester
Product Overview

This testing device conforms to IEC62262 and is used for mechanical strength testing of sheet metal components such as substation arks and metalloid electric energy metering cubicles. The mounting bracket and impact angle are adjustable, designed for energy impact testing with energy levels exceeding 2J.

Technical Parameters

Pendulum Specifications:

  • Length: 1000mm
  • External diameter: 15.9 mm
  • Thickness: 1.5 mm
  • Material: Steel

The impact height is adjustable from 200-1200mm and can be customized. The impact apparatus can be moved on all sides.

Striking Elements Features
Energy (J) ≤1 ±10% 2 ±5% 5 ±5% 10 ±5% 20 ±5% 50 ±5%
Equivalent mass ±2% (kg) 0.25(0.2) 0.5 1.7 5 5 10
Material Nylon Steel Steel Steel Steel Steel
R (mm) 10 25 25 50 50 50
D (mm) 18.5(20) 35 60 80 100 125
f (mm) 6.2(10) 7 10 20 20 25
r (mm) - - 6 - 10 17
Height of Falling
Energy (J) 0.14 0.2 (0.3) 0.35 (0.4) 0.5 0.7 1 2 5 10 20 50
Equivalent mass (kg) 0.25 (0.2) 0.25 (0.2) 0.25 (0.2) (0.2) 0.25 0.25 0.5 1.7 5 10
Dropping height ±1% (mm) 56 (100) 80 (150) 140 (200) (250) 200 280 400 300 200 400
IK Code and Corresponding Impact Energy
IK Code IK00 IK01 IK02 IK03 IK04 IK05 IK06 IK07 IK08 IK09 IK10
Impact Energy (J) a 0.14 0.2 0.35 0.5 0.7 1 2 5 10 20
Product Images
UP-3012 High Energy Pendulum Impact Tester with 2J to 50J Range and Adjustable Height for IEC62262 Compliance UP-3012 High Energy Pendulum Impact Tester with 2J to 50J Range and Adjustable Height for IEC62262 Compliance UP-3012 High Energy Pendulum Impact Tester with 2J to 50J Range and Adjustable Height for IEC62262 Compliance
Our Service

During the entire business process, we offer Consultative Selling services:

1) Customer Inquiry Process:
Discussing testing requirements and technical details, suggesting suitable products, and providing competitive pricing.
2) Specifications Customize Process:
Creating detailed drawings for customized requirements, providing reference photos, and confirming final solutions and pricing.
3) Production and Delivery Process:
Manufacturing according to confirmed requirements, providing production progress photos, conducting calibration, and ensuring timely delivery.
4) Installation and After-Sale Service:
Providing installation support and comprehensive after-sales service.
Frequently Asked Questions
1. Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?

Yes, we are a professional manufacturer of Environmental Chambers, Leather shoe testing equipment, and Plastic Rubber testing Equipment in China. Every machine purchased from our factory has a 12-month warranty after shipment. We offer 12 months of FREE maintenance, extended to 14 months considering sea transportation. If your machine doesn't work, contact us via email or phone, and we'll provide solutions within 24-48 hours.

2. What about the delivery term?

For standard machines in stock: 3-7 working days. For non-stock items: 15-20 working days after payment. Urgent requirements receive special arrangements.

3. Do you accept customization services? Can I have my logo on the machine?

Yes, we offer both standard and customized machines according to your requirements. We provide OEM and ODM services, including placing your logo on the machine.

4. How can I install and use the machine?

We provide English operation manuals and videos via email. Most machines are shipped fully assembled - simply connect the power cable and begin use. On-site installation assistance is available when necessary.
