UP-6115 Hanging Basket Cold And Hot Temperature Chamber , Impact Test Chamber For IC Chip
UP-6115 Hanging Basket Cold And Hot Temperature Chamber , Impact Test Chamber For IC Chip
UP-6115 Hanging Basket Cold And Hot Temperature Chamber , Impact Test Chamber For IC Chip
UP-6115 Hanging Basket Cold And Hot Temperature Chamber , Impact Test Chamber For IC Chip
Specifications
Certification :
CE,ISO
MOQ :
1 Unit
Price :
Negotiable
Brand Name :
YOUBI
Model Number :
UP-6115
Place of Origin :
CHINA
Payment Terms :
T/T,D/P,Western Union,Paypal,Money Gram
Supply Ability :
30 Unit/month
Delivery Time :
5-15 work days
Packaging Details :
Professional Export Wooden Box Packaging
Product name :
Hot Temperature Chamber
Warranty :
1 Year
Color Service :
Support Customer Customization
Size Service :
Support Customer Customization
Third-Party Calibration Service :
Support Customer Customization
Temperature range :
-120ºC~225ºC
Temperature accuracy :
±1ºC
Custom Service :
OEM,ODM
Description

UP-6115 Hanging Basket Cold and Hot Temperature Impact Test Chamber for IC Chip

The manufacturing of semiconductors electronic components for harsh environments, the IC package assembly and test stages of engineering and production include burn-in, electronic hot and cold testing at temperature, and Inother environmental test simulations.

This system has the same function as high and low temperature shock test chamber.

Specification:

External dimension (air) cm

45*85*130

55*95*170

70*100*175

80*120*185

100*150*185

Dimension (water) cm

45*85*130

45*85*130

55*95*170

70*100*175

80*120*185

Air cooled type

It adopts copper tube and aluminum fin condensing mode and upper air outlet type.

The condensing fan adopts German EBM axial flow fan

Water cooled

The model with W is water-cooled

water-cooled condenser

Tubular heat exchanger (Paris / Shen)

Cooling water at 25 ºC

0.6m3/h

1.5m3/h

2.6m3/h

3.6m3/h

7m3/h

Power supply: 380V, 50Hz

4.5kw max

6.8kw max

9.2kw max

12.5kw max

16.5kw max

Power Supply

Can be customized 460V 60Hz, 220V 60Hz three-phase

Shell material

Plastic spraying of cold rolled sheet (standard color 7035)

Temperature expansion

High temperature to + 300 ºC



UP-6115 Hanging Basket Cold And Hot Temperature Chamber , Impact Test Chamber For IC Chip
UP-6115 Hanging Basket Cold And Hot Temperature Chamber , Impact Test Chamber For IC Chip
UP-6115 Hanging Basket Cold And Hot Temperature Chamber , Impact Test Chamber For IC Chip
UP-6115 Hanging Basket Cold And Hot Temperature Chamber , Impact Test Chamber For IC Chip
Our service:
During the whole business process, we offer a Consultative Selling services.
1)Customer inquiry process:
Discussing testing requirements and technical details, suggested suitable products to customer to confirm.
Then quote the most suitable price according to customer requirements.

2)Specifications customize process:
Drawing related drawings to confirm with customer for customized requirements. Offer reference photos to show the appearance of the product. Then, confirm the final solution and confirm the final price with the customer.

3)Production and delivery process:
We will produce the machines according to confirmed PO requirements. Offering photos to show the production process.
After finishing production, offer photos to the customer to confirm again with the machine. Then do your own factory calibration or third-party calibration(as per customer requirements). Check and test all the details and then arrange packing.
Delivering the products is confirmed shipping time and informed the customer.

4)Installation and after-sale service:
Defines installing those products in the field and providing after-sales support.

FAQ:
1. Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?
Yes, we are the one of professional manufacturers of Environmental Chambers, Leather shoe testing equipment, and Plastic Rubber testing Equipment... in China. Every machine purchased from our factory has 12 month warranty after shipment. Generally, we offer 12 months for FREE maintenance. while considering sea transportation, we can extend 2 months for our customers.
Moreover, If your machine doesn't work, you can send us an e-mail or call us we will try our best to find the problem through our conversation or by video chat if necessary. Once we have confirmed the problem, the solution will be offered within 24 to 48 hours.
2. What about the delivery term?
For our standard machine which means normal machines, If we have stock in the warehouse, is 3-7 working days;
If there is no stock, normally, the delivery time is 15-20 working days after payment is received;
If you are in urgent need, we will make a special arrangement for you.
3. Do you accept customization services? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines but also customized machines according to your requirements. And we can also put your logo on the machine which means we offer OEM and ODM service.
4. How can I install and use the machine?
Once you have ordered the testing machines from us, we will send you the operation manual or video in English version through Email.
Most of our machine is shipped with a whole part, which means it is already installed, you just need to connect the power cable and start to use it. And if it's necessary, we can also assist you to install your machine on-site.
