KUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 Compatible
KUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 Compatible
KUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 Compatible
KUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 Compatible
KUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 Compatible
KUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 Compatible
KUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 Compatible
KUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 Compatible
KUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 Compatible
KUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 Compatible
KUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 Compatible
KUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 Compatible
Specifications
Model Number :
KC-RJ45-01
Place of Origin :
Guangdong, China
Certification :
CE,RoHS
Packaging Details :
PE Bag,carton
MOQ :
500 pieces
Price :
$0.55/pieces 500-999 pieces
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
1000PCS/Per Week
Delivery Time :
15days
Type :
RJ45
Brand :
KUNCAN
Packaging :
Bulk in the carton
Description :
ethernet socket rj45 to rj45 connector
D/C :
RJ45-01
Product name :
ethernet socket rj45 to rj45 connector
Color :
Black or custom
application :
CAT5/CAT5e/CAT6/CAT7/CAT8
Materials :
ABS
Shield :
UTP/FTP/SFTP
Warranty :
1 year
Size :
1.57"*0.78"*0.78"
Description

RJ45 Female to Female Ethernet Coupler Socket

Cat6/5e Compatible • 10Gbps Ready • PoE++ Supported

TIA-568-C.2 Certified Gold Plated Contacts Shielded Option Tool-less Installation
[High-res coupler front/back view] [Side-by-side comparison with competitors] [Installation diagram]

Technical Specifications

  • Connector Type: 8P8C (RJ45) Female-Female
  • Compatibility: Cat6, Cat5e, Cat5
  • Bandwidth: 550MHz (Cat6 rated)
  • Contact Plating: 50μm gold over nickel
  • PoE Support: Up to IEEE 802.3bt (90W)
  • Insertion Loss: ≤0.3dB @ 250MHz
  • Wiring Standard: T568A/B compatible
  • Mounting Style: Keystone, Inline, Panel-mount

Available Variants

  • Shielding: UTP or STP (EMI/RFI protection)
  • Housing Material: PC/ABS or metal
  • Color: Black, White
  • Termination Type: Punch-down or IDC

Key Features

Precision Alignment

Machined contacts ensure perfect conductor alignment for minimal insertion loss and crosstalk.

High-Power PoE++

Thick gold plating supports 802.3bt PoE++ for IP cameras, WiFi 6 APs, and LED lighting.

Universal Compatibility

Works with all standard RJ45 plugs including Cat6, Cat5e, and molded strain relief connectors.

Performance Specifications

Parameter Specification
Contact Resistance ≤ 20mΩ initially, ≤ 25mΩ after 1000 cycles
Insulation Resistance ≥ 1000MΩ @ 500VDC
Dielectric Withstanding Voltage 1000VAC RMS for 1 minute
Operating Temperature -40°C to +85°C (-40°F to +185°F)
Mating Cycles ≥ 1000 insertion/extractions
Wire Gauge Compatibility 22-26 AWG solid or stranded

Recommended Applications

Network Infrastructure

  • Extending patch cables in server racks
  • Joining cable runs through conduit
  • Quick repairs without re-termination

Security Systems

  • IP camera installations with PoE+
  • Connecting pre-terminated NVR cables
  • Field termination points

Smart Buildings

  • Modular office partitions
  • Floor box connections
  • HDBaseT signal extension
Product Description

KUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 CompatibleKUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 CompatibleKUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 CompatibleKUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 CompatibleKUNCAN RJ45 Ethernet Coupler UTP/FTP/SFTP Shield Cat6 Compatible




Category Cat5/Cat5e/Cat6/Cat7
Size 1.57"*0.78"*0.78"
Material ABS+copper
Shied

UTP(unshielded twisted pair), FTP(shielded foil twisted pair)

SFTP(shielded foil twisted pair)
Color Black/Red/White/Grey/Blue/Green,etc
Certification USA,CE,RoHS
Application Network Modem,LE Plate,Wall Socket,PC


FAQ

Q1.Are you factory or trade company?

A:We are factory of more than 16 years export experience.

Q2.What is your terms of payment?

A:T/T 30% as deposit, and 70% before delivery.

Q3.What is your terms of delivery?

A:EXW, FOB, CFR, CIF, DDU.

Q4.Samples ?

A:2-5 pieces free samples are available,fright on you. Delivery time usually is 2-3 days. Customized samples will take 5-10days.

Q5.What is delivery time if we place an order?

A:It depends order quantities.Usually,we can deliver goods within 10-15 working days,for more QTY order,let's confirm when you place official order.

Q6.Do you test all your goods before delivery?

A:Yes, we have 100% test before delivery.

Q7:How to ship out the cargo?

A:At your request, by sea,by express, all are available.
