KS30-CS High Accuracy SF6 Gas Tester with Constant-Temperature Adiabatic Design for Dew Point Testing
KS30-CS High Accuracy SF6 Gas Tester with Constant-Temperature Adiabatic Design for Dew Point Testing
Specifications
Power Supply :
Lithium battery or AC/DC dual-use
Brand Name :
KSTONE
Model Number :
KS30-CS
Certification :
ISO9000
Place of Origin :
Shanghai
MOQ :
5
Payment Terms :
T/T
Supply Ability :
100 per year
Delivery Time :
7-10 work days
Packaging Details :
Carton / Wooden Box
Dew Point Testing :
-80°C to +20°C range, ±0.5°C accuracy
Moisture Range :
0.05–23,100 μL/L
Purity Measurement :
0–100% range, ±0.5% accuracy
Dimensions :
414 x 333 x 177 mm, 3kg weight
Sample Gas Flow :
0.2 ±30% L/min
Description
KS30-CS SF6 Gas Tester - High Accuracy Dew Point Purity Analyzer for SEA Power & Chemical Industries
Advanced SF6 Gas Analysis Solution

The KS30-CS SF6 Gas Tester by KSTONE represents cutting-edge technology in gas analysis, specifically engineered for the demanding environments of Southeast Asia's power and chemical industries. With innovative constant-temperature adiabatic design and exceptional measurement precision, this analyzer ensures reliable performance in challenging tropical conditions.

Critical Importance of SF6 Gas Analysis

Sulfur hexafluoride (SF6) gas is essential for electrical insulation and arc quenching in high-voltage equipment like circuit breakers and switchgear. In chemical processes, it plays vital roles. However, impurities or moisture can compromise equipment performance, cause costly downtime, and create safety hazards. For rapidly industrializing regions like Thailand, Malaysia, Indonesia, and Vietnam, maintaining SF6 gas purity and dryness is crucial for infrastructure reliability.

Key Technical Features
  • Constant-Temperature Adiabatic Design: Minimizes impact of sample gas temperature and ambient humidity, ensuring consistent results in Southeast Asia's tropical climate
  • High-Accuracy Measurements: Precise purity and dew point testing with exceptional repeatability
  • Rapid Response Time: Achieves readings in as little as 5 seconds for specific dew point transitions
  • User-Friendly Operation: Color touch screen with intuitive graphical interface reduces learning curve
  • Durable & Portable: Long-life detection module, robust components, and compact design (only 3kg weight)
  • Versatile Applications: Supports purity measurements for various gas mixtures including H2 & N2
Technical Specifications
Parameter Specification
Purity Measurement Range 0-100%
Purity Measurement Accuracy ±0.5%
Dew Point Range -80°C to +20°C
Dew Point Accuracy ±0.5°C
Repeatability ±0.2°C
Moisture Range 0.05-23,100 μL/L
Sample Gas Flow 0.2 ±30% L/min
Power Supply Lithium battery or AC/DC dual-use
Dimensions 414 x 333 x 177 mm
Weight 3kg
Industry Applications
  • Power Industry: Monitor SF6 gas purity and moisture levels in high-voltage electrical equipment
  • Chemical & Petrochemical: Safeguard processes relying on SF6 or other specialty gases
  • Metallurgy & Steel Manufacturing: Maintain operational efficiency with precise gas analysis
  • Gas Production & Distribution: Verify gas quality and compliance with industry standards
Operational Advantages

Reliability in Challenging Environments: The adiabatic design ensures measurement accuracy despite Southeast Asia's high humidity and temperature fluctuations.

Cost-Effective Operation: Fast response time and minimal maintenance requirements reduce operational downtime and costs.

Compliance & Safety: Enables adherence to international standards while mitigating risks from gas impurities.

Manufacturer Excellence

KSTONE, an ISO9001-certified company based in Shanghai, delivers high-quality industrial testing solutions. With a supply capacity of 100 units annually and delivery within 10 working days, we're positioned to support operations across Southeast Asia with innovation, precision, and customer satisfaction.

Invest in the KS30-CS SF6 Gas Tester today for smarter, safer, and more efficient gas management solutions.
