Specifications
Brand Name :
Schneider
Model Number :
8751019000
Certification :
CE RoHS
Place of Origin :
EU
MOQ :
5
Payment Terms :
Western Union,T/T
Delivery Time :
7 Days
Packaging Details :
Carton
Description
8751019000 Schneider Non-Spring Return Damper Actuator 24V 10Nm 0-10V New
Product Overview

The Schneider Electric Non-Spring-Return Damper Actuator (Part No. 8751019000) provides 10 Nm torque with 0-10V proportional control, manual override, and position feedback — designed for medium-to-large HVAC dampers requiring precise modulating control in commercial building automation.

Technical Specifications
Part Number 8751019000
Power Supply 24 VAC
Torque 10 Nm
Control Signal 0-10V DC (proportional)
Position Feedback 0-10V
Manual Override Yes
Spring Return No
Rotation Angle 0-95° (adjustable)
Enclosure IP54
Key Features
  • 10 Nm torque output for medium-to-large dampers
  • 0-10V proportional control signal
  • 0-10V position feedback
  • Manual override capability
  • Non-spring return operation
  • Adjustable 0-95° rotation angle
  • IP54 rated enclosure for dust and water protection
Applications
Applied on medium-to-large AHU dampers including mixed air, outdoor air, recirculation, and energy recovery bypass dampers. The doubled torque (versus 8751009000) accommodates larger damper leaf areas and higher duct static pressures. Used in VAV system terminal unit bypass dampers, smoke control smoke exhaust dampers (non-fire-rated applications), and large floor-by-floor fresh air intake shafts.
Brand new, original Schneider Electric product.
