Anti‑PID 700W Monocrystalline Solar Panel, 25% Extra Rear‑Side Power Generation
Anti‑PID 700W Monocrystalline Solar Panel, 25% Extra Rear‑Side Power Generation
Anti‑PID 700W Monocrystalline Solar Panel, 25% Extra Rear‑Side Power Generation
Anti‑PID 700W Monocrystalline Solar Panel, 25% Extra Rear‑Side Power Generation
Specifications
Front Glass Thickness :
3.2 mm
Cell Dimensions :
166 mm × 83 mm
Delivery Time :
general two weeks, more quantity based on exact quantity
Maximum Power :
700W
Model Number :
KM500-600W Solar Panel
System Voltage :
1500 V DC
Junction Box Current :
25A
Supply Ability :
10000pcs/month
Bifaciality Factor :
85%
Payment Terms :
L/C,L/C
Weight :
25 kg
Place of Origin :
China
Cell Type :
Monocrystalline / Polycrystalline
Encapsulation Material :
EVA
Price :
USD1-100/pcs
Packaging Details :
standard international carton packing
Dimensions :
1722x1134x30mm
Brand Name :
Kuoman
Panel Efficiency :
22%
MOQ :
1
Number of Cells :
144
Description
Anti-PID 700W Monocrystalline Solar Panel, 25% Extra Rear-Side Power Generation
Our 700W double-glass HJT monocrystalline bifacial PV module adopts advanced 16BB SMBB solar-cell technology, delivering high conversion efficiency up to 22.53%. Built with dual 2.0 mm semi-tempered glass, this durable solar panel supports a maximum 25% rear-side power gain thanks to its 85% bifaciality factor. Rated for 1500 V DC system voltage and tough-condition-resistant, this industrial-grade solar module is engineered for long-term outdoor power generation for residential, commercial and utility-scale solar projects.
Anti‑PID 700W Monocrystalline Solar Panel, 25% Extra Rear‑Side Power Generation Anti‑PID 700W Monocrystalline Solar Panel, 25% Extra Rear‑Side Power Generation
Electrical Specifications
Parameter 680W 690W 700W 710W 720W
Maximum Power (Pmax/W) 680 690 700 710 720
Maximum Power Voltage (Vmp/V) 41.49 41.80 42.10 42.40 42.70
Maximum Power Current (Lmp/A) 16.39 16.51 16.63 16.75 16.87
Open Circuit Voltage (Voc/V) 49.5 49.82 50.13 50.45 50.76
Short Circuit Current (Lsc/A) 17.19 17.31 17.43 17.55 17.67
Module Efficiency (%) 21.89 22.21 22.53 22.85 23.18
Anti‑PID 700W Monocrystalline Solar Panel, 25% Extra Rear‑Side Power Generation
Shipping Methods
Shipping Methods Arrive At Delivery From
By Sea Sea Port Any port in China
By Air Specification Any port in China
By Railway Your door Any railway station
By Express Specification Zhengzhou City
Mechanical Characteristics
  • Dimensions: 2108 mm in length, 1048 mm in width, and 35 mm in height (L×W×H)
  • Weight: 25 kg per module
  • Front Glass: 3.2 mm thick, high-transmission tempered glass for maximum light penetration and impact resistance
  • Encapsulation: High-quality EVA (Ethylene Vinyl Acetate) for cell protection and durability
  • Cells: 144 pieces of monocrystalline solar cells, each measuring 166 mm × 83 mm
  • Backsheet: Composite film providing excellent insulation and weather resistance
  • Frame: Anodized aluminum profile offering corrosion resistance and structural strength
  • Junction Box: Rated at 25A current, IP68 waterproof rating, TUV certified for safety and reliability
  • Cable: Negative cable length 400 mm, Positive cable length 300 mm
  • Connector: Compatible with industry-standard MC4 connectors for easy and secure installation
General Product Questions
What types of solar panels does Kuoman offer?
Kuoman Solar manufactures two main product lines: high-strength aluminum frame rigid panels (100W-500W) for residential, commercial, and utility-scale installations, and ultra-lightweight ETFE flexible panels (30W-500W) for RVs, marine applications, outdoor adventures, and OEM integration.
What is the efficiency of your solar panels?
Our rigid panels achieve up to 21.1% module efficiency, while our flexible ETFE panels feature high-efficiency PERC cells with up to 23.0% conversion efficiency, among the highest in the flexible solar category.
Are Kuoman panels suitable for high-temperature environments like deserts or tropical regions?
Yes. Our panels feature an ultra-low power temperature coefficient of -0.39%/°C, meaning they lose less efficiency in high heat compared to standard panels. They are tested for continuous operation from -40°C to +85°C.
Do you offer bifacial or shingled cell technology?
Yes. Our flexible ETFE series incorporates bifacial transparent encapsulation for rear-side light harvesting, and select models feature shingled (imbrication) cell architecture to maximize active area and efficiency.
