Home Rooftop 200W‑210W High‑Efficiency Solar Panel, 19.01%‑19.96% Conversion Mono PV Module
Home Rooftop 200W‑210W High‑Efficiency Solar Panel, 19.01%‑19.96% Conversion Mono PV Module
Home Rooftop 200W‑210W High‑Efficiency Solar Panel, 19.01%‑19.96% Conversion Mono PV Module
Home Rooftop 200W‑210W High‑Efficiency Solar Panel, 19.01%‑19.96% Conversion Mono PV Module
Specifications
Model Number :
JST-EXMH-(200-210)W
Max Series Fuse :
15A
Supply Ability :
2000 pcs/month
Voltage at Pmax :
19.06V
Power Tolerance :
0 ~ +4.99W
Module Efficiency :
20.01%
MOQ :
1 Container
Open Circuit Voltage :
21.96V
Price :
based on quantity
Maximum Power :
210W
Maximum System Voltage :
700Vdc
Payment Terms :
T/T
Current at Pmax :
11.02A
Place of Origin :
China
Packaging Details :
1425*1100*885mm
Short Circuit Current :
11.58A
Brand Name :
KUOMAN
Temperature Coefficient :
-0.350%/°C
Description
Home Rooftop 200W‑210W High‑Efficiency Solar Panel, 19.01%‑19.96% Conversion Mono PV Module
Product Overview

With best-in-class efficiency of 20.01% (210W model), it delivers maximum power output while maintaining a compact footprint. Ideal for users seeking to minimize installation space without compromising energy generation.

Home Rooftop 200W‑210W High‑Efficiency Solar Panel, 19.01%‑19.96% Conversion Mono PV Module

Technical Specifications
Parameter 200W Model 210W Model
Maximum Power (Pmax) 200W 210W
Open Circuit Voltage (Voc) 21.79V 21.96V
Short Circuit Current (Isc) 11.24A 11.58A
Voltage at Pmax (Vmp) 18.76V 19.06V
Current at Pmax (Imp) 10.66A 11.02A
Module Efficiency 19.01% 20.01%
Power Tolerance 0 ~ +4.99W 0 ~ +4.99W
Maximum System Voltage 700Vdc (IEC/UL) 700Vdc (IEC/UL)
Max Series Fuse Rating 15A 15A
Key Features & Benefits
  • Unmatched Efficiency & Power Density - 20.01% module efficiency (210W) generates more electricity per square meter than competing panels. High power output (210W) in compact size (1375 * 765 * 30mm) maximizes roof or ground space.
  • Superior Temperature Performance - Low temperature coefficient (-0.350%/°C for Pmax) ensures minimal power loss in hot climates.
  • Industrial-Grade Durability - IP67 junction box (waterproof to 1m for 30 minutes) and 3.2mm tempered glass resist moisture, dust, and impact. 5400Pa front wind load / 2400Pa rear snow load rating for harsh environmental resilience.
  • Scalable & Future-Proof - 700V system voltage supports large series connections for utility-grade or industrial systems. Customizable cable lengths (90cm standard) and MC4 compatibility simplify complex PV array integration.
Competitive Advantages
  • Higher ROI - Positive power tolerance (+4.99W) means you often get more power than rated
  • 24V System Optimized - Vmp (19.06V) aligns perfectly with 24V battery charging, reducing energy loss
  • Global Certifications - Meets IEC/UL standards for safety and performance worldwide
Frequently Asked Questions
Can this panel charge a 48V battery?
Yes! Wire two panels in series (total ~38V) for 48V battery systems with a compatible charge controller.
How many panels fit on one pallet?
36 panels per pallet (dimensions: 1425*1100*885mm; weight: 425kg).
Is it suitable for coastal areas?
Absolutely. The IP67 junction box and corrosion-resistant aluminum frame withstand salt, moisture, and UV degradation.
Home Rooftop 200W‑210W High‑Efficiency Solar Panel, 19.01%‑19.96% Conversion Mono PV ModuleApplication Scenarios
Large Off-Grid Homes
Primary power for remote cabins, farms, or eco-resorts
Commercial Rooftops
Small businesses, warehouses, or agricultural facilities seeking energy independence
Telecom & Utilities
Powers remote cell towers, weather stations, or grid-tied backup systems
Mobile Applications
Heavy-duty RV solar systems, large boats, or mobile command centers
