60‑Watt Outdoor Monocrystalline Solar Panel High Mechanical Load Capacity Wind Snow Proof PV Panel
60‑Watt Outdoor Monocrystalline Solar Panel High Mechanical Load Capacity Wind Snow Proof PV Panel
60‑Watt Outdoor Monocrystalline Solar Panel High Mechanical Load Capacity Wind Snow Proof PV Panel
60‑Watt Outdoor Monocrystalline Solar Panel High Mechanical Load Capacity Wind Snow Proof PV Panel
Specifications
Model Number :
KM500-600W Solar Panel
Inverter Compatibility :
Micro-inverter, string inverter
Maximum Power :
60W
Supply Ability :
10000pcs/month
Voltage :
24 volts
Power Output :
Customized
Type :
Photovoltaic
Short-Circuit Current :
3.16A
Material :
Silicon
Dimensions :
855 x 395 x 25 mm
MOQ :
1
Weather Resistance :
IP65
Price :
USD1-100/pcs
Packaging Details :
standard international carton packing
Current :
12.5 amps
Open Circuit Voltage :
23.18V
Warranty :
25 years
Payment Terms :
L/C,L/C
Size :
60 x 40 inches
Place of Origin :
China
Module Efficiency :
17.77%
Panel Efficiency :
22%
Delivery Time :
general two weeks, more quantity based on exact quantity
Panel Dimensions :
1903x1134x35mm
Brand Name :
Kuoman
Certifications :
UL, CE, TUV
Color :
Blue or Black
Name :
Common Solar Panel
Weight :
3.8 kg
Description
60‑Watt Outdoor Monocrystalline Solar Panel High Mechanical Load Capacity Wind Snow Proof PV Panel

With a peak power output of 60W, 17.77% module efficiency and sturdy aluminum‑framed tempered‑glass construction, this compact‑size solar module delivers stable off‑grid power generation. It works reliably under harsh outdoor temperatures, compatible with MC4‑standard connectors for quick installation for home, camping, RV and remote‑location power supply.

60‑Watt Outdoor Monocrystalline Solar Panel High Mechanical Load Capacity Wind Snow Proof PV Panel

Key Parameters
  • Electrical (STC):
    • Maximum Power (Pmax): 60W
    • Open Circuit Voltage (Voc): 23.18V
    • Short-Circuit Current (Isc): 3.16A
    • Voltage at Pmax (Vmp): 20.00V
    • Current at Pmax (Imp): 3.00A
    • Module Efficiency: 17.77%
    • Max System Voltage: 700V DC
  • Mechanical Specifications:
    • Dimensions: 855 x 395 x 25 mm
    • Weight: 3.8 kg
    • Solar Cells: 34 pieces, Monocrystalline 182x45.5mm
    • Frame: Anodized Aluminum
    • Front Glass: 3.2mm Tempered Glass
    • Junction Box: IP67 rated
    • Connectors: MC4 Compatible
  • Temperature & Packaging:
    • Operating Temperature: -40°C to +85°C
    • Pmax Temperature Coefficient: -0.35%/°C
    • Pieces per Pallet: 80 pcs
Key Features
  1. Optimized 60W Power Output:​ Features 34 high-grade monocrystalline cells, providing an ideal balance of higher voltage (20Vmp) and robust current (3A Imp) for faster battery charging.
  2. Industrial-Grade Durability:​ Built with 3.2mm tempered glass, a sturdy aluminum frame, and an IP67-rated junction box to withstand harsh weather, moisture, and mechanical stress.
  3. Superior Energy Harvest:​ A high module efficiency of 17.77% and a favorable temperature coefficient ensure maximum energy yield and stable performance in high-temperature conditions.
  4. Ready for Professional Installation:​ Includes pre-drilled mounting holes, industry-standard MC4 connectors, and supports a high 700V system voltage for flexible, scalable system design.
Application Scenarios
  • RV, caravan, camper‑van and marine boat off‑grid charging
  • Outdoor camping, backyard shed, garden lighting power supply
  • Remote farm equipment, surveillance camera, street‑light power source
  • Home emergency backup power, tiny‑house off‑grid solar kits
  • Portable outdoor power station, battery bank daily charging
  • Traffic signs, outdoor billboard and remote‑sensor power supply
60‑Watt Outdoor Monocrystalline Solar Panel High Mechanical Load Capacity Wind Snow Proof PV Panel
Frequently Asked Questions
What is the operating voltage of this 60‑watt solar panel?

The optimal working voltage under STC condition is 20.00V, perfect for charging 12V storage batteries.

Can this solar panel work in freezing or high‑temperature environments?

Yes. Its operating‑temperature range spans -40℃ to +85℃, suitable for extreme cold and hot outdoor surroundings.

How much wind pressure can the solar panel endure?

The front face withstands 5400Pa load and the rear side bears 2400Pa, strong enough against heavy wind and snow.
