70W High Performance Monocrystalline PV Module, Excellent Low‑Light Output Outdoor Camping Solar Panel
70W High Performance Monocrystalline PV Module, Excellent Low‑Light Output Outdoor Camping Solar Panel
70W High Performance Monocrystalline PV Module, Excellent Low‑Light Output Outdoor Camping Solar Panel
70W High Performance Monocrystalline PV Module, Excellent Low‑Light Output Outdoor Camping Solar Panel
Specifications
Delivery Time :
general two weeks, more quantity based on exact quantity
Module Efficiency :
17.77%
Model Number :
KM500-600W Solar Panel
Max Power Output :
410W-430W
Price :
USD1-100/pcs
Packaging Details :
standard international carton packing
Max Power :
70W
Supply Ability :
10000pcs/month
Open Circuit Voltage :
23.18V
Output Frequency :
60Hz/50Hz
Payment Terms :
T/T
Dimensions :
1650 x 992 x 40 mm
Connector Type :
MC4 Compatible
Front Glass :
3.2mm High Transmission Tempered
Place of Origin :
China
Vmp At Stc :
37.5V
MOQ :
1
Nominal Voltage :
48V DC
Max System Voltage :
1000V/1500V DC
Brand Name :
Kuoman
Temperature Coefficient :
-0.38%/°C
Description
70W High Performance Monocrystalline PV Module, Excellent Low‑Light Output Outdoor Camping Solar Panel
Product Overview

Unlock reliable, clean energy with this premium 70-watt monocrystalline solar panel. Engineered for exceptional efficiency and durability, this compact module delivers superior performance for a wide range of off-grid and mobile applications, making it the smart choice for sustainable power.

70W High Performance Monocrystalline PV Module, Excellent Low‑Light Output Outdoor Camping Solar Panel
Technical Specifications
Electrical Characteristics (STC) Value
Maximum Power (Pmax) 70W
Open Circuit Voltage (Voc) 17.59V
Short-Circuit Current (Isc) 2.55A
Voltage at Pmax (Vmp) 16.53V
Current at Pmax (Imp) 2.42A
Maximum System Voltage 700V DC
Power Tolerance 0 to +4.99W
Mechanical Specifications Value
Dimensions 985 × 395 × 30 mm
Weight 4.24 kg
Solar Cells Monocrystalline 182mm (28 cells, 2x14 configuration)
Frame Anodized Aluminum Alloy
Front Glass 3.2mm Tempered Glass
Junction Box IP67 rated, with 50cm output wires (custom length available) and MC4-compatible connectors
Mechanical Load Capacity 5400Pa (Front) / 2400Pa (Rear)
Temperature & Operational Ratings Value
Operating Temperature -40°C to +85°C
Nominal Operating Cell Temperature (NOCT) 45±2°C
Pmax Temperature Coefficient -0.35%/°C
Key Features
  • Rated maximum power: 70W, Open-circuit Voltage 20.42V, Working Voltage 17.50V
  • High-efficiency 182mm monocrystalline solar cells, 17.99% conversion efficiency
  • Heavy-duty 3.2 mm tempered anti-reflective front glass for better light capture
  • Corrosion-resistant sturdy aluminium frame, adaptable for long-time outdoor installation
  • IP67 waterproof rated junction box, rain-proof, dust-proof and weather-sealed
  • Compatible with MC4 standard solar panel connectors, 50cm customizable-length output cables
  • Wide operating temperature: -40℃ ~ +85℃, excellent low-light power-generating capability
  • Certified 700VDC maximum system voltage, 10A maximum series fuse rating for safety
  • High mechanical load resistance: 5400Pa front load and 2400Pa rear-side load
  • Compact dimension 985×395×30mm, lightweight 4.24kg for easy transport and mounting
Application Scenarios
  • Recreational Vehicles (RVs) & Campers: Maintain house batteries while on the road or at the campsite.
  • Marine & Boating: Provide auxiliary power for trolling motors, onboard electronics, and battery maintenance on sailboats and fishing boats.
  • Off-Grid Cabins & Sheds: Serve as a primary or supplementary power source for remote buildings and weekend getaways.
  • Remote Monitoring Systems: Power security cameras, weather stations, and communication equipment in areas without grid access.
70W High Performance Monocrystalline PV Module, Excellent Low‑Light Output Outdoor Camping Solar PanelPackaging

80pcs per pallet (Pallet Dimensions: 630×1100×930mm, approximately 235kg).
