5.8G 7W Wireless Video Transmitter Ultra Long Range Image Sender 80CH RC Drone Accessories
5.8G 7W Wireless Video Transmitter Ultra Long Range Image Sender 80CH RC Drone Accessories
5.8G 7W Wireless Video Transmitter Ultra Long Range Image Sender 80CH RC Drone Accessories
5.8G 7W Wireless Video Transmitter Ultra Long Range Image Sender 80CH RC Drone Accessories
5.8G 7W Wireless Video Transmitter Ultra Long Range Image Sender 80CH RC Drone Accessories
5.8G 7W Wireless Video Transmitter Ultra Long Range Image Sender 80CH RC Drone Accessories
5.8G 7W Wireless Video Transmitter Ultra Long Range Image Sender 80CH RC Drone Accessories
5.8G 7W Wireless Video Transmitter Ultra Long Range Image Sender 80CH RC Drone Accessories
Specifications
Brand Name :
Kimpok
Model Number :
KP-T58770
Certification :
CE Cerfication
Place of Origin :
China
MOQ :
1 piece
Price :
Negotiation
Payment Terms :
T/T, PayPal or western Union
Supply Ability :
3,000 pieces per month
Delivery Time :
3-7 work days
Packaging Details :
International standard packing
Type :
Wireless video transmission
Frequency :
4.9-6G(4990M-5945M)
Protocol :
IRC Tramp
Power Supply :
7-36V
Channel :
80 CH
Weight :
56g
Description

5.8G 7W Wireless Video Transmitter Ultra Long Range Image Sender 80CH RC Drone Accessories

I.Specifications

1. 4.9GHz-6GHz 80 个CH: (4990MHz-5945MHz)

2. Max power: 7W (1W/2.5W/5W/7W adjustable)

3. Input voltage: DC 15V-36V, supporting 2-8S battery input

4. Antenna connector: SMA inner hole

5. Smart audio: IRC Tramp

6. Heat-dissipating method: aluminum alloy shell, heat sink&fan

7. Hole spacing: 20mm*20mm/ø2mm

8. Dimension: 64.13mm*37.2mm*17.2mm

9. Weight: 56g

II. Function Introduction

5.8G 7W Wireless Video Transmitter Ultra Long Range Image Sender 80CH RC Drone Accessories

1. Channel indicator: Red LED

2. Band indicator: Blue LED

3. Power indicator: Green LED

4. Band & Channel changer button

5. Power changer button

6. 1.0 6P Power connector

7. SMA Mother seat inner hole

III. Notice for Use:

1. The VTX must be installed with space to ensure that the air convection around the module to ensure that the module heat dissipation; otherwise, the module overheating protection start, reduce the power to transmit, or even shut down the power to transmit.

2. It is recommended that before turning on the power, to ensure that the correct voltage range, positive and negative poles are correct, so as not to burn components.

3. It is recommended that before turning on the power, make sure that the RF RF output has been installed antenna, which can extend the life of the module.

4. Please read the instruction manual before use, so that you can correctly wire and extend the module service life.

5.8G 7W Wireless Video Transmitter Ultra Long Range Image Sender 80CH RC Drone Accessories5.8G 7W Wireless Video Transmitter Ultra Long Range Image Sender 80CH RC Drone Accessories5.8G 7W Wireless Video Transmitter Ultra Long Range Image Sender 80CH RC Drone Accessories5.8G 7W Wireless Video Transmitter Ultra Long Range Image Sender 80CH RC Drone Accessories
