3.3GHz 3W 64CH Analog Video Transmitter with IRC Control for FPV and UAV Applications
3.3GHz 3W 64CH Analog Video Transmitter with IRC Control for FPV and UAV Applications
3.3GHz 3W 64CH Analog Video Transmitter with IRC Control for FPV and UAV Applications
3.3GHz 3W 64CH Analog Video Transmitter with IRC Control for FPV and UAV Applications
3.3GHz 3W 64CH Analog Video Transmitter with IRC Control for FPV and UAV Applications
3.3GHz 3W 64CH Analog Video Transmitter with IRC Control for FPV and UAV Applications
Specifications
Brand Name :
Kimpok
Model Number :
ALV3303AC
Certification :
CE Cerfication
Place of Origin :
China
MOQ :
10
Price :
Negotiation
Payment Terms :
D/P,Western Union,Paypal
Supply Ability :
5,000 pieces per month
Delivery Time :
3-5 work days
Packaging Details :
Internatianal Standard Packing
Frequency :
3.3GHz
Max Power :
3000mW
Channel :
64 Channels
Video Type :
Analog
Voltage Input :
Wide Voltage
Antenna Type :
SMA
Description

3.3GHz 3W 64CH Analog Video Transmitter with IRC Control for FPV and UAV Applications


Product Introduction

The ALV3303AC is a compact 3.3GHz analog video transmitter designed for professional FPV and UAV applications requiring stable medium-to-long range video transmission. With support for 64 channels and IRC protocol, it offers flexible configuration and reliable performance in complex RF environments.

Key Features

  • 3.3GHz frequency band with 64 channels

  • Switchable output power: Pit / 1W / 3W

  • IRC protocol support

  • LED display with single-button control

  • Wide voltage input: 7–26V

  • 5V camera power output

Advantages

  • Excellent balance between power consumption and transmission range

  • Strong anti-interference capability in crowded 5.8GHz environments

  • Easy integration with FPV flight controllers

  • Stable analog signal with low latency

Applications

  • FPV long-range drones

  • UAV training platforms

  • Industrial monitoring drones

  • Fixed-wing UAV systems

Specifications

Item Description
Frequency Range 3.06–3.5GHz
Channels 64CH
Output Power Pit / 1W / 3W
Input Voltage 7–26V
Camera Output 5V ≤500mA
Control Button + LED
Protocol IRC
Antenna Connector SMA
Mounting 30.5 × 30.5mm
Weight ~40g
