Kimpok 4.8GHz-7.2GHz High Sensitivity Analog Video Receiver Data Module, Long Range Wireless Data Module with LED Display Auto-Search
Kimpok 4.8GHz-7.2GHz High Sensitivity Analog Video Receiver Data Module, Long Range Wireless Data Module with LED Display Auto-Search
Kimpok 4.8GHz-7.2GHz High Sensitivity Analog Video Receiver Data Module, Long Range Wireless Data Module with LED Display Auto-Search
Kimpok 4.8GHz-7.2GHz High Sensitivity Analog Video Receiver Data Module, Long Range Wireless Data Module with LED Display Auto-Search
Kimpok 4.8GHz-7.2GHz High Sensitivity Analog Video Receiver Data Module, Long Range Wireless Data Module with LED Display Auto-Search
Kimpok 4.8GHz-7.2GHz High Sensitivity Analog Video Receiver Data Module, Long Range Wireless Data Module with LED Display Auto-Search
Kimpok 4.8GHz-7.2GHz High Sensitivity Analog Video Receiver Data Module, Long Range Wireless Data Module with LED Display Auto-Search
Kimpok 4.8GHz-7.2GHz High Sensitivity Analog Video Receiver Data Module, Long Range Wireless Data Module with LED Display Auto-Search
Specifications
Input Voltage :
DC 5V
Place of Origin :
China
Model Number :
4.8GHz-7.2GHz VRX
MOQ :
1
Delivery Time :
5-7 work days
Antenna Interface :
SMA-F
Payment Terms :
L/C,D/P
Frequency Range :
4.8GHz - 7.2GHz (4867MHz - 7210MHz)
Receiver Sensitivity :
-95dBm
Price :
Negotiation
Channel Capacity :
Multi-Band Support (BAND A to V)
Supply Ability :
2,0000 pieces per month
Product Name :
Wireless Video Receiver Data Module
Certification :
CE Cerfication
Brand Name :
Kimpok
Packaging Details :
International Standard Packing
Description

Kimpok 4.8GHz-7.2GHz High Sensitivity Analog Video Receiver Data Module, Long Range Wireless Data Module with LED Display Auto-Search


The 4.8GHz–7.2GHz Analog Video Receiver Data Module is a high-performance, ultra-wideband wireless data receiver designed for long-range analog video transmission. Engineered with a compact footprint (44mm × 27mm), it covers an extensive frequency spectrum (4867MHz–7210MHz) across 176 channels (Band A–V) to ensure signal clarity and minimize interference.

Featuring advanced Phase-Locked Loop (PLL) frequency control, an impressive -95dBm sensitivity, and a standard 50Ω SMA-F antenna interface, the module delivers stable, low-latency analog video output (1Vp-p, 75Ω) in complex RF environments.

The integrated dual 7-segment LED display and intuitive control buttons allow quick channel switching and one-touch automatic frequency searching. Operating on a 5V DC supply with built-in RSSI signal output, it is an ideal embedded solution for advanced wireless data reception systems.


Kimpok 4.8GHz-7.2GHz High Sensitivity Analog Video Receiver Data Module, Long Range Wireless Data Module with LED Display Auto-Search

Kimpok 4.8GHz-7.2GHz High Sensitivity Analog Video Receiver Data Module, Long Range Wireless Data Module with LED Display Auto-Search

Kimpok 4.8GHz-7.2GHz High Sensitivity Analog Video Receiver Data Module, Long Range Wireless Data Module with LED Display Auto-Search
