Specifications
Place of Origin :
Guangdong, China
Brand Name :
KSPOWER
Model Number :
KSHL
Certification :
UL/cUL/CE/TUV-GS/RoHS/Class2
MOQ :
5 pieces
Price :
$14.58-59.88/pieces
Warranty(Year) :
5-Year
Lighting solutions service :
Lighting and circuitry design
Output Power :
100w 120w 150w 200w
Output Type :
PWM
Input Voltage :
100-277VAC
Output Frequency :
50/60Hz
Output Current :
2.08A-16.66A
Product Name :
100W-200W Dimming led driver
Material :
Aluminum Case
Warranty :
5 years
Protection :
OCP, OVP, SCP, OTP
IP Rate :
IP65:IP67
Efficiency :
≥91%
Power :
100w 120w 150w 200w
Output :
12V 24V
Application :
LED Strip Light,Pendants, Linears,Cove Lights
Description
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Products Description

0-10v led tv backlight driver dc 12v 24v 100w 120w 150w 200w ultra slim led driver 12v driver for led ceiling fan

Input Voltage
100~277V AC 47~63Hz
Power Factor
PF≧0 98/115VAC, PF≧0 95/230VAC, PF≧0.9/277VAC, 80% with load
NO.
KSHL
Output Voltage
12volts/ 24volts/ 36volts/48volts
Rated Current
0.62A-16.66A
Rated Power
30w 40w 60w 80w 96w 100w 120w 150w 180w 200w 240w 300w 320w
Certification
UL/cUL/CE/TUV-GS/RoHS/FCC/Class2
Features:
− Universal AC input voltage 100-277VAC − Efficiency up to 91% − Built-in active PFC function − Single channel & constant voltage mode and PWM style output − Protection: OCP, OVP, SCP, OTP − Limited Power Source − cUL, RoHS, CE, ENEC, GS, Class P, SAA Approved − Function options: 1. Non-dimmable 2. Triac/Phase-cut Dimmable 3. 4 in 1 dimmable (0-10V,1-10V,PWM,resistance) 4. 5 in 1 dimmable (0-10V,1-10V,TRIAC,PWM,resistance) − Typical lifetime > 50000 hours − 5 years warranty − Available with or without integrated Junction Box − IP65 IP67 Rated Enclosure for Indoor and Outdoor Use − Wiring Compartments with Knock-Outs for Clean and Easy Installation

Note:Any custom label/package/case is acceptable, provide OEM and ODM service
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Show Details
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
NOW,GET MORE INFORMATIONS OF US !
Company Profile
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Working Room
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Exhibition
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Certifications
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Applications
Ultra Slim 0-10v LED Dimmer TV Backlight 24v 200W For LED Ceiling Fan And Strip IP67 Rate
Product packaging
1.Sample is available.
2.Shipping method: available for express DHL/UPS/FedEx/TNT, Land, Ocean and others.
3. for 60W power adapter : each one put in one small inner brown box, then 50 pcs put in one standard carton.
Package
Piece/Carton(pcs)
Piece Weight(KG)
OEM package
50
0.26
Dimension/Brown Box(mm)
Dimension/Carton(mm)
Gross Weight/Carton(KG)
155*85*35
455*370*175
14
