Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type
Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type
Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type
Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type
Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type
Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type
Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type
Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type
Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type
Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type
Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type
Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type
Specifications
Place of Origin :
Guangdong, China
Brand Name :
KSPOWER
Model Number :
KS-240AW-12P
Certification :
UL FCC CE ROHS SAA CLASS 2 CLASS P etc.
MOQ :
10 pieces
Price :
$45/pieces >=10 pieces
Payment Terms :
T/T
Supply Ability :
300000pcs/monthly
Delivery Time :
20-25 days
Packaging Details :
Small box and Cartons
Warranty(Year) :
5-Year
Lighting solutions service :
Lighting and circuitry design
Output Power :
40 - 320W
Output Type :
PWM
Input Voltage :
100-277V
Output Frequency :
50/60Hz
Product :
waterproof electronic led driver
Application :
LED Strip Light,Pendants, Linears,Cove Lights
Material :
Plastic case
Warranty :
5 years
Protection :
OCP, OVP, SCP, OTP
IP Rate :
IP65
Efficiency :
≥90%
Output :
12V24V36V48V
Description
IP67 240W Dimmable LED Driver

Perfect for Outdoor Dimmable LED Strip Installations
The KS-240W is a versatile 240W 5-in-1 universal dimming driver that accepts 100-277VAC input voltage and provides 12V, 24V, 36V, and 48V constant voltage output. This driver delivers flicker-free dimming to 0% on all dimming systems including Triac, 0-10V, 1-10V, PWM, Resistance, MLV, ELV, and Incandescent. The high efficiency and sophisticated overload protection enable the electronics to run cooler, significantly improving reliability and extending product life.
The compact metal case is dry/damp location listed and IP65 rated, making it suitable for a wide range of indoor/outdoor architectural, commercial, industrial, and residential lighting applications. The KS-80W is available with or without integrated junction boxes on both the input and output side, each featuring two knockouts.
Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type
Key Features
  • Input Voltage: Universal 100VAC to 277VAC, 50/60Hz for Residential, Commercial, and Industrial Use
  • Single Channel & Constant Voltage mode
  • Output Voltage: 12V/24V/36V/48V
  • Driver Type: Class 2 Class P
  • Enclosure: LISTED Enclosure with Junction Box / LISTED Enclosure without Junction Box
  • Dimming: PWM, TRIAC, 0/1-10V or MLV / ELV Resistance Dimmable Available
  • Environmental: Dry and Damp
  • Wiring Compartments with Knock-Outs for Clean and Easy Installation
  • Current Limiting Overload Protection
  • Flicker-Free
  • Smooth Ripple Free Output Voltage
  • IP65 Rated Enclosure for Indoor and Outdoor Use
  • 5-Years Warranty
  • UL/cUL CE FCC RoHS ENEC GS Listed, SELV, Type Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type

Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type

Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type Electronic Magnitude Magnetic LED Dimmer 12v 300w For LED Strip Lights PWM Output Type
Technical Specifications
Dimming Type Series Power Model (xx=output voltage) Output Voltage & Current Input Voltage Size
5 in 1 dimming HPJ 40W KS-40AW-xxP 12V:3.3A, 24V:1.67A, 36V:1.11A, 48V:0.83A 100~277V 50/60Hz 297*58*36mm
5 in 1 dimming HPJ 60W KS-60AW-xxP 12V:5A, 24V:2.5A, 36V:1.67A, 48V:1.25A 100~277V 50/60Hz 297*58*36mm
5 in 1 dimming HPJ 80W KS-80AW-xxP 12V:6.67A, 24V:3.33A, 36V:2.22A, 48V:1.67A 100~277V 50/60Hz 297*58*36mm
5 in 1 dimming HPJ 96W KS-96AW-24P 24V:4A 100~277V 50/60Hz 322*58*36mm
5 in 1 dimming HPJ 100W KS-100AW-xxP 12V:8.33A, 24V:4.16A, 36V:2.78A, 48V:2.08A 100~277V 50/60Hz 322*58*36mm
5 in 1 dimming HPJ 120W KS-120AW-xxP 12V:10A, 24V:5A, 36V:3.33A, 48V:2.5A 100~277V 50/60Hz 322*58*36mm
5 in 1 dimming HPJ 150W KS-150AW-xxP 12V:12.5A, 24V:6.25A, 36V:4.16A, 48V:3.13A 100~277V 50/60Hz 343*68*41mm
5 in 1 dimming HPJ 180W KS-180AW-12P 12V:15A 100~277V 50/60Hz 343*68*41mm
5 in 1 dimming HPJ 200W KS-200AW-xxP 12V:16.66A, 24V:8.33A, 36V:5.55A, 48V:4.16A 100~277V 50/60Hz 343*68*41mm
5 in 1 dimming HPJ 240W KS-240AW-xxP 12V:20A, 24V:10A, 36V:6.66A, 48V:5A 100~277V 50/60Hz 367*68*41mm
5 in 1 dimming HPJ 300W KS-300AW-24P 24V:12.5A 100~277V 50/60Hz 367*68*41mm
5 in 1 dimming HPJ 320W KS-320AW-xxP 24V:13.33A, 36V:8.88A, 48V:6.66A 100~277V 50/60Hz 367*68*41mm
Custom labeling, packaging, and cases are available. We provide OEM and ODM services.
