Specifications
Brand Name :
Canaan Kaixinlong
Model Number :
NJP-800
Place of Origin :
Wenzhou China
MOQ :
1
Price :
19500$
Payment Terms :
T/T, L/C
Packaging Details :
The size of non-fumigated wooden cases varies according to the size of the machine
Output :
800 Capsules/min
No.of segment bores :
6
Suitable fof capsule :
00#-5#
Total power :
4.5Kw(standard)
Overall weight :
1000Kgs
Overall diemensions :
840(+339)mm×820(+339)mm×2000mm
Description

Overview of the machine:

Automated Pharmaceutical machine Pharmaceutical technology Pellet filling machine Pharmaceutical factory

The NJP-800 series capsule filling machine designed and produced by our factory has been improved and innovated for many times, and is the preferred equipment for hospitals and small and medium-sized pharmaceutical factories, replacing the original semi-automatic capsule filling equipment.
The whole machine adopts intermittent rotary mechanism and quantitative filling. Suitable for 00 # -5 # capsule powder and capsule filling, and can be equipped with automatic bag delivery machine, vacuum feeding machine, gold inspection machine, polishing machine, hoist and other auxiliary equipment.

Technical parameters:

Output 800Capsules/min
No.of segment bores36 6
Suitable fof capsule 00#-5#
Total power 4.5Kw(Standard configuration)
Overall weight90 1000Kgs
Overall diemensions
840(+339)mm×820(+339)mm×2000m
Noise ≤75DB(A)
Pressure 0.4 ~ 0.7Mpa
Air consumption ≤6m³
Vacuum -0.03 ~ -0.06Mpa
Filling error ±2.5%~±5%

The machine may make technical improvements without prior notice, and the attached picture shows the options that may be offered.

Closed station turntable:

1.Use the imported silicone sealing ring to reduce the condition that the powder is brought into the turntable due to the expansion of the movement axis, and smooth operation, high accuracy;
2.It solves the complicated problem of installing and dismantling the mold, reduces the labor intensity of the staff, and strengthens the service life of the station rotary table.

4.5Kw Automated Capsule Filling Machine Pharmaceutical technology

Three-dimensional adjustment mechanism:

1.Eliminate the metering plate, copper ring natural deformation degree, uniform clearance, reduce the phenomenon of powder leakage;
2.Easy to disassemble and disassemble, easy to clean;
3.Ensure device differences.
4.5Kw Automated Capsule Filling Machine Pharmaceutical technology
