Specifications
Brand Name :
Canaan Kaixinlong
Model Number :
NJP-400
Place of Origin :
Wenzhou China
MOQ :
1
Price :
18000$
Payment Terms :
T/T, L/C
Packaging Details :
The size of non-fumigated wooden cases varies according to the size of the machine
Output :
400 Capsules/min
Suitable fof capsule :
00#-5#
Overall weight :
900Kgs
Noise :
≤75DB（A）
Air consumption :
≤6m³
Filling error :
±2.5%~±5%
Description

Overview of the machine:

High Quality Capsule Filling Machine Hard Capsule Filling Machine Pellet Filling Machine Pharmaceutical Factory

The NJP-400 series capsule filling machine designed and produced by our factory has been improved and innovated for many times, and is the preferred equipment for hospitals and small and medium-sized pharmaceutical factories, replacing the original semi-automatic capsule filling equipment.
The whole machine adopts intermittent rotary mechanism and quantitative filling. Suitable for 00 # -5 # capsule powder and capsule filling, and can be equipped with automatic bag delivery machine, vacuum feeding machine, gold inspection machine, polishing machine, hoist and other auxiliary equipment.

Technical parameters:

Output 400Capsules/min
No.of segment bores36 3
Suitable fof capsule 00#-5#
Total power 4Kw(Standard configuration)
Overall weight90 900Kgs
Overall diemensions 760(+304)mm*780mm(+304)*1900mm
Noise ≤75DB(A)
Pressure 0.4 ~ 0.7Mpa
Air consumption ≤6m³
Vacuum -0.03 ~ -0.06Mpa
Filling error ±2.5%~±5%

The machine may make technical improvements without prior notice, and the attached picture shows the options that may be offered.

Pellet / powder Capsule Filling Machine Factory Pharmaceutical equipment Pellet / powder Capsule Filling Machine Factory Pharmaceutical equipment Pellet / powder Capsule Filling Machine Factory Pharmaceutical equipment
Capsule polisher(option) Capsule polisher with sorter(option) Vertical capsule polisher(option)

1.Capsule special polishing equipment, can remove the dust and static electricity on the surface of the capsule, improve the surface smooth.

2.Using infinite speed regulating motor, hopper height adjustable.

1.In addition to dust and polishing, eliminate static electricity, can also automatically remove the loading, shell, debris and body separation capsules.

2.Using frequency conversion speed regulation, sensitive and reliable speed can withstand a large start torque, synchronous belt output power to achieve low noise operation.

1.With capsule polishing, sorting, and improved functions, leaving high space for connecting to subsequent devices.

2.The entrance and exit can be adjusted by 360° circumference to facilitate production and save floor space.

3.The use of fast assembly connection structure makes the disassembly and installation of the machine more convenient and quick.

Copper collar:

Pellet / powder Capsule Filling Machine Factory Pharmaceutical equipment
1.Hard column: stable particle weight, loading amount close to the maximum value, one or two groups of filling rods have obvious beating, the adjustment range is too small, the machine load is large, the corresponding parts wear fast.
2.Soft column: stable grain weight, large adjustment range, small load, small wear of parts.
Half column: sometimes appear puff powder particle weight and light.
3.Scattered sand: leakage, dirty machine table, installation difference. The gap type copper ring can be replaced with the sealing type.
Pellet / powder Capsule Filling Machine Factory Pharmaceutical equipment According to the material situation, the company provides the optional replacement copper ring

Vacuum separation mechanism:

Pellet / powder Capsule Filling Machine Factory Pharmaceutical equipment
