4Kw Powder capsule manufacturing machine Pellet Filling Machine
4Kw Powder capsule manufacturing machine Pellet Filling Machine
4Kw Powder capsule manufacturing machine Pellet Filling Machine
4Kw Powder capsule manufacturing machine Pellet Filling Machine
4Kw Powder capsule manufacturing machine Pellet Filling Machine
4Kw Powder capsule manufacturing machine Pellet Filling Machine
4Kw Powder capsule manufacturing machine Pellet Filling Machine
4Kw Powder capsule manufacturing machine Pellet Filling Machine
4Kw Powder capsule manufacturing machine Pellet Filling Machine
4Kw Powder capsule manufacturing machine Pellet Filling Machine
4Kw Powder capsule manufacturing machine Pellet Filling Machine
4Kw Powder capsule manufacturing machine Pellet Filling Machine
Specifications
Brand Name :
Canaan Kaixinlong
Model Number :
NJP-400
Place of Origin :
Wenzhou China
MOQ :
1
Price :
18000$
Payment Terms :
T/T, L/C
Packaging Details :
The size of non-fumigated wooden cases varies according to the size of the machine
Output :
400 Capsules/min
No.of segment bores :
3
Suitable fof capsule :
00#-5#
Total power :
4KW
Overall weight :
900Kgs
Overall diemensions :
760(+304)mm*780mm(+304)*1900mm
Description

Capsule Filling Machine Manufacturer Powder Capsule Filling Machine Pharmaceutical Technology Pellet Filling Machine

Technical parameters:

Output 400Capsules/min
No.of segment bores36 3
Suitable fof capsule 00#-5#
Total power 4Kw(Standard configuration)
Overall weight90 900Kgs
Overall diemensions 760(+304)mm*780mm(+304)*1900mm
Noise ≤75DB(A)
Pressure 0.4 ~ 0.7Mpa
Air consumption ≤6m³
Vacuum -0.03 ~ -0.06Mpa
Filling error ±2.5%~±5%

The machine may make technical improvements without prior notice, and the attached picture shows the options that may be offered.

Orientation of the empty capsule:

Broadcast description
The capsule head always acts in the middle of the capsule body, and the capsule head pushes the capsule to make a U-turn movement, which always pushes the capsule body to the edge of the capsule comb, and then presses the capsule head down to turn the capsule over and push it vertically into the module hole.
principle
1. The thrust point of the capsule head is on the capsule body;
2. The width of the chute is smaller than the outer diameter of the capsule cap, which is larger than the outer diameter of the capsule body. It only has a tightness effect on the capsule cap and does not contact with the capsule body.
Orientation of the empty capsule

4Kw Powder capsule manufacturing machine Pellet Filling Machine

Capsule feeding method:

4Kw Powder capsule manufacturing machine Pellet Filling Machine

Feeding manually:

1.The capsule was manually added to the capsule bucket.
2.Applicable for smaller batch production

4Kw Powder capsule manufacturing machine Pellet Filling Machine
Automatic transfer of empty capsule(option)

The bottom capsule delivery tube is connected to the compressed air, and the automatic capsule delivery machine delivers the capsule to the capsule bucket, without the need for manual capsule addition.
Automatic bag delivery machine is easy to operate, can automatically start and stop feeding, to ensure the continuity of the machine operation.

Closed station turntable:

1.Use the imported silicone sealing ring to reduce the condition that the powder is brought into the turntable due to the expansion of the movement axis, and smooth operation, high accuracy;
2.It solves the complicated problem of installing and dismantling the mold, reduces the labor intensity of the staff, and strengthens the service life of the station rotary table.

4Kw Powder capsule manufacturing machine Pellet Filling Machine
