JY-BFTC-615+ LTCC Bandpass Filter 450-780 MHz 50 Ohm Surface Mount RoHS Compliant
JY-BFTC-615+ LTCC Bandpass Filter 450-780 MHz 50 Ohm Surface Mount RoHS Compliant
Specifications
Brand Name :
JYRF
Interface :
SMT
Certification :
RoHS Compliant
Technology :
LTCC
Model Number :
JY-BFTC-615+
Impedance :
50 Ohm
Place of Origin :
China
Passband :
450-780 MHz
Stopband Rejection :
20 dB @ 1-320 MHz; 20 dB @ 970-2400 MHz
Product Type :
LTCC Bandpass Filter
Description

JY-BFTC-615+ LTCC Bandpass Filter

Product Overview

JY-BFTC-615+ is a LTCC Bandpass Filter with 450-780 MHz passband, 50 ohm impedance in a SMT package. It offers low insertion loss and high stopband rejection, making it ideal for RF front-end and communication applications.

Electrical Specifications

ParameterSpecificationTest Condition
Passband450-780 MHz50 Ohm system
Stopband Rejection20 dB @ 1-320 MHzF3
Stopband Rejection20 dB @ 970-2400 MHzF4
Impedance50 Ohm-
TechnologyLTCC-
InterfaceSMT-

Features

  • Low insertion loss across the passband
  • High rejection at both lower and upper stopbands
  • Compact SMD package for space-constrained PCB design
  • 50 ohm impedance, matched for RF system design
  • RoHS compliant and suitable for lead-free soldering

Applications

  • RF transceiver front-ends
  • Communication systems
  • Signal conditioning and test equipment
  • Band selection and channel filtering

Packaging

Products are supplied in tape and reel packaging, ready for automated SMT assembly.
