CAT7 SFTP LAN Cable 1000FT 23AWG Solid Copper LSZH 10Gbps Data Center & Industrial Cable
CAT7 SFTP LAN Cable 1000FT 23AWG Solid Copper LSZH 10Gbps Data Center & Industrial Cable
CAT7 SFTP LAN Cable 1000FT 23AWG Solid Copper LSZH 10Gbps Data Center & Industrial Cable
CAT7 SFTP LAN Cable 1000FT 23AWG Solid Copper LSZH 10Gbps Data Center & Industrial Cable
CAT7 SFTP LAN Cable 1000FT 23AWG Solid Copper LSZH 10Gbps Data Center & Industrial Cable
CAT7 SFTP LAN Cable 1000FT 23AWG Solid Copper LSZH 10Gbps Data Center & Industrial Cable
Specifications
Brand Name :
ITI-LINK
Model Number :
ITI-CT7SF-020
Certification :
UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
Place of Origin :
SHENZHEN
MOQ :
1000pcs
Price :
$50-$100
Payment Terms :
T/T
Supply Ability :
1000pcs/day
Delivery Time :
15-45 Days
Packaging Details :
Wooden shaft packaging 40*26*20cm Outer box size：42*42*22cm
Shielding Type :
CAT7 SFTP
Conductor Size :
23AWG
Frequency :
600MHz
Jacket Material :
PVC/LSZH
Speed :
Up to 10Gbps
Conductor Material :
Copper
Jacket Color :
Orange
Cable Length :
1000FT (Bulk)
Description

CAT7 SFTP LAN Cable 1000FT 23AWG Solid Copper LSZH 10Gbps Data Center & Industrial Cable

Product Description:

Professional CAT7 SFTP Shielded LAN Cable built with 23AWG solid copper, double shielding, and LSZH jacket. Supports 600MHz bandwidth and stable 10Gbps transmission for data center and industrial network applications.


① Product Overview
The ITI-LINK ITI-CT7SF-020 CAT7 SFTP Shielded LAN Cable is a professional-grade network cable designed for data center and industrial network installations. Supplied in a 1000FT bulk length, it supports large-scale structured cabling projects with high performance and reliability.

② Performance
With support for up to 10Gbps Ethernet transmission and 600MHz bandwidth, this CAT7 SFTP Cable ensures fast, stable, and low-latency data transfer. The shielded LAN cable design effectively minimizes electromagnetic interference (EMI) and crosstalk.

③ Structure & Materials
The cable is constructed with 23AWG solid oxygen-free copper conductors. Each twisted pair features individual foil shielding, combined with an overall braided shield. The orange LSZH/PVC jacket provides enhanced durability, fire safety, and easy identification.

④ Application Value
Designed as a professional Data Center Cable and Industrial Network Cable, this CAT7 SFTP Shielded Ethernet Cable performs reliably in high-interference environments and continuous data-load applications.

⑤ Brand Trust
ITI-LINK delivers reliable networking solutions manufactured to international standards, trusted by engineers and system integrators worldwide.

Technical Parameters:

Product Description: CAT7 SFTP LAN Cable 1000FT 23AWG Solid Copper LSZH 10Gbps Data Center & Industrial Cable
Rev.: A ECN Description:
Construction Item Description Electrical Property


Conductor


Material

Bare Solid Copper(elongation:

19-24%)

 Conductor Resistance at 20°C ≤ 9.5 Ω / 100m
OD 23 AWG Resistance unbalance within a pair ≤ 2%






Insulation

 Material PE Skin-Foam-Skin Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V


>1500 MΩ / 100m
OD 1.33 ±0.01 mm Mutual capacitance 5600 pF / 100m MAX
Average THK 0.37mm Capacitance unbalance pair to ground at 800Hz or 1 kHz ≤ 160 pF / 100m



Color

 1p: white + 2 blue stripes & blue Characteristic impedance at 100MHz 100 ± 15 Ω

2p: white + 2 orange stripes &

orange

Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or

0.7 KV AC for 1 min


No breakdown
3p: white + 2 green stripes & green Mechanical Property
4p: white + 2 brown stripes & brown



insulation

 elongation before aging ≥ 300%



Pair Twist



Lay & Direction

 1p: S=19.0 mm (28%) tensile strength before aging ≥16 MPa
2p: S=23.5 mm (31%) elongation after aging ≥ 150 %
3p: S=21.5 mm (33%) tensile strength after aging ≥10.5 MPa
4p: S=25.0 mm (36%)



jacket

 elongation before aging ≥ 125 %
OD / tensile strength before aging ≥ 10 MPa


Inner Assemble

 Lay S=90 ± 5 mm elongation after aging ≥ 100 %
Direction according to the drawing tensile strength after aging ≥ 8 MPa
OD / Packing


Filler

 Ripcord 3*250D Drum NA
Drain Wire /



Pair Shield

 Shield Pair Shield






Construction /
Material Polyester/Aluminium (PET/ALU)
Coverage ≥ 115%


Braid

 Material ɸ 0.12mm Aluminum-magnesium braided
Coverage ≥ 40%





Jacket

 Material LSZH, 60P, -20~75℃
Hardness 81± 3
OD 8.1 ± 0.2
Average THK 0.55 ~ 0.65


Color

 orange
Marking Color black
Marking

according to the customer's

requirements



Electrical Properties
Conductor Resistance at 20°C NF EN 50289-1-2 / IEC 60189-1 ≤ 9.5 Ω / 100m
Resistance unbalance within a pair NF EN 50289-1-2/ IEC 60708 ≤ 2%

Dielectric Strength

Test Voltage (cd/cd): 1.00KV DC or 0.7 KV AC for 1 min Test Voltage (cd/screen): 1.00KV DC or 0.7 KV AC for 1 min


NF EN 50289-1-3 / IEC 61196-1-105


No breakdown
Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V


NF EN 50289-1-4 / IEC 60885-1

 >1500 MΩ / 100m
Mutual capacitance NF EN 50289-1-5 /IEC 60189-1 5600pF / 100m MAX
Capacitance unbalance pair to ground at 800Hz or 1 kHz NF EN 50289-1-5 / IEC 60189-1 ≤ 160 pF / 100m
Characteristic impedance at 100MHz NF EN 50289-1-11/ IEC 61156-1 100 ± 15 Ω
Spark Test UL444 2000 ± 250VOC


Applications:

  • Data center structured cabling systems requiring CAT7 SFTP shielded LAN cable
  • Industrial automation networks with high EMI environments
  • 5G base station backhaul and communication rooms
  • Enterprise network infrastructure and server rooms
  • Power industry monitoring, control, and communication networks
  • High-bandwidth video streaming and data-intensive systems
