CAT7 SFTP Shielded LAN Cable 1000FT 10Gbps 600MHz LSZH Solid Copper
CAT7 SFTP Shielded LAN Cable 1000FT 10Gbps 600MHz LSZH Solid Copper
CAT7 SFTP Shielded LAN Cable 1000FT 10Gbps 600MHz LSZH Solid Copper
CAT7 SFTP Shielded LAN Cable 1000FT 10Gbps 600MHz LSZH Solid Copper
CAT7 SFTP Shielded LAN Cable 1000FT 10Gbps 600MHz LSZH Solid Copper
CAT7 SFTP Shielded LAN Cable 1000FT 10Gbps 600MHz LSZH Solid Copper
Specifications
Brand Name :
ITI-LINK
Model Number :
ITI-CT7SF-018
Certification :
UL, ETL, CSA, RCM, TUV, CPR, CE, RoHS
Place of Origin :
SHENZHEN
MOQ :
1000pcs
Price :
50$-100$
Payment Terms :
T/T
Supply Ability :
1500pcs/day
Delivery Time :
15-45 Days
Packaging Details :
Color Box+Packing Box 36*36*21cm
Cable Type :
CAT7
Jacket Material :
LSZH
Shielding Type :
SFTP
Conductor Material :
Copper
Frequency :
600MHz
Jacket Color :
White
Data Rate :
10Gbps
Conductor Size :
23AWG
Description

CAT7 SFTP Shielded LAN Cable 1000FT 10Gbps 600MHz LSZH Solid Copper

Product Description:

The ITI-LINK ITI-CT7SF-018 CAT7 SFTP Cable is a high-performance shielded LAN cable designed for demanding network environments. Built with 23AWG solid oxygen-free copper conductors and advanced SFTP shielding, it supports stable 10Gbps data transmission at up to 600MHz. The LSZH black jacket enhances fire safety, making it ideal for data centers, industrial networks, 5G infrastructure, and enterprise applications.


① Product Overview: The ITI-LINK ITI-CT7SF-018 CAT7 SFTP Cable is a professional-grade shielded LAN cable developed for high-speed and interference-sensitive network deployments. Designed to meet modern Ethernet requirements, it provides reliable connectivity for industrial, commercial, and data center environments.

② Performance: With a bandwidth of up to 600MHz, this CAT7 SFTP cable supports stable 10Gbps data transmission. Its superior shielding structure minimizes signal loss, crosstalk, and electromagnetic interference, ensuring consistent performance across long cable runs.

③ Structure & Materials: The cable is constructed using 23AWG solid oxygen-free copper conductors for optimal conductivity. Each twisted pair is individually foil-shielded, combined with an overall braided shield. The LSZH PVC/PE black jacket provides enhanced fire safety and mechanical durability.

④ Application Value: This shielded LAN cable is suitable for data center cabling, industrial Ethernet networks, enterprise LANs, and 5G communication systems where stability and safety are critical.

⑤ Brand Trust: ITI-LINK is committed to delivering high-quality network cable solutions with consistent performance and reliable manufacturing standards for global customers.

Technical Parameters:

Product Description:

CAT7 SFTP Shielded LAN Cable 1000FT 10Gbps 600MHz LSZH Solid Copper
Rev.: A ECN Description:
Construction Item Description Electrical Property


Conductor


Material

Bare Solid Copper(elongation:

19-24%)

 Conductor Resistance at 20°C ≤ 9.5 Ω / 100m
OD 23 AWG Resistance unbalance within a pair ≤ 2%






Insulation

 Material PE Skin-Foam-Skin Insulation Resistance at 20°C after 2min of electrification under a DC voltage between 100 & 500V


>1500 MΩ / 100m
OD 1.33 ±0.01 mm Mutual capacitance 5600 pF / 100m MAX
Average THK 0.37mm Capacitance unbalance pair to ground at 800Hz or 1 kHz ≤ 160 pF / 100m



Color

 1p: white + 2 blue stripes & blue Characteristic impedance at 100MHz 100 ± 15 Ω

2p: white + 2 orange stripes &

orange

Dielectric Strength Test Voltage (cd/cd,cd/screen): 1.00KV DC or

0.7 KV AC for 1 min


No breakdown
3p: white + 2 green stripes & green Mechanical Property
4p: white + 2 brown stripes & brown



insulation

 elongation before aging ≥ 300%



Pair Twist



Lay & Direction

 1p: S=19.0 mm (28%) tensile strength before aging ≥16 MPa
2p: S=23.5 mm (31%) elongation after aging ≥ 150 %
3p: S=21.5 mm (33%) tensile strength after aging ≥10.5 MPa
4p: S=25.0 mm (36%)



jacket

 elongation before aging ≥ 125 %
OD / tensile strength before aging ≥ 10 MPa


Inner Assemble

 Lay S=90 ± 5 mm elongation after aging ≥ 100 %
Direction according to the drawing tensile strength after aging ≥ 8 MPa
OD / Packing


Filler

 Ripcord 3*250D Drum NA
Drain Wire /



Pair Shield

 Shield Pair Shield






Construction /
Material Polyester/Aluminium (PET/ALU)
Coverage ≥ 115%


Braid

 Material ɸ 0.12mm Aluminum-magnesium braided
Coverage ≥ 40%





Jacket

 Material LSZH, 60P, -20~75℃
Hardness 81± 3
OD 8.1 ± 0.2
Average THK 0.55 ~ 0.65


Color

 black
Marking Color

according to the customer's

requirements
Marking

according to the customer's

requirements


Applications:

Data Centers & Server Rooms
Designed as a professional data center cable, this CAT7 SFTP shielded LAN cable supports backbone and horizontal cabling with stable 10Gbps performance.

Industrial Networks & Automation
Ideal for industrial Ethernet, PLC systems, and factory automation where shielding is essential to prevent signal interference.

5G Communication & Telecom Facilities
Suitable for 5G base stations, telecom rooms, and edge computing nodes requiring high-speed and reliable connectivity.

Commercial & Enterprise Buildings
Perfect for enterprise LANs, security systems, IP cameras, and structured cabling projects with strict safety standards.

Power & Utility Applications
Well-suited for smart grid networks, substations, and monitoring systems requiring interference-resistant data transmission.
