Radiator Cooling Fan Blade Assembly 360 mm Diameter 5-Blade Design OEM 16361-0D070 for Toyota Corolla Altis 1.6L 1.8L 2003-2007
Radiator Cooling Fan Blade Assembly 360 mm Diameter 5-Blade Design OEM 16361-0D070 for Toyota Corolla Altis 1.6L 1.8L 2003-2007
Radiator Cooling Fan Blade Assembly 360 mm Diameter 5-Blade Design OEM 16361-0D070 for Toyota Corolla Altis 1.6L 1.8L 2003-2007
Radiator Cooling Fan Blade Assembly 360 mm Diameter 5-Blade Design OEM 16361-0D070 for Toyota Corolla Altis 1.6L 1.8L 2003-2007
Specifications
Payment Terms :
T/T,
Carton Dimensions :
40 × 40 × 10 cm
Model Number :
Toyota Corolla Altis
Blade Diameter :
360 mm
MOQ :
5 pcs
Delivery Time :
5-8 Work Days
Cooling Type :
Engine coolant circulation
Price :
Negotiable
Net Weight :
0.8-1.2 kg
Certifiion :
ISO/TS16949
Voltage :
12V DC
Supply Ability :
10000 pcs/month
Master Carton :
50 units
Brand Name :
YIMI
Number of Blades :
5
Packaging Details :
Neutral Package or as customers’ request
Place of Origin :
China
Material :
High-strength aluminum alloy & precision bearings
Description
Radiator Cooling Fan Blade Assembly 16361-0D070 For Toyota Corolla Altis 1.6L 1.8L 2003-2007
Product Overview

The radiator cooling fan blade carrying Toyota OEM number 16361-0D070 is a direct replacement for the fan blade component within the radiator cooling fan assembly. This part is designed for the Toyota Corolla and Corolla Altis (E120, E130 series) manufactured between 2001 and 2007.

The fan blade is the physical moving part that pulls air through the radiator and air conditioning condenser. It is mounted to the fan motor and spins to draw cooling airflow across the radiator fins. This airflow is critical for maintaining proper engine coolant temperature and ensuring the air conditioning system delivers cold air, particularly during low-speed driving, idling, or when the vehicle is stationary in traffic.

Radiator Cooling Fan Blade Assembly 360 mm Diameter 5-Blade Design OEM 16361-0D070 for Toyota Corolla Altis 1.6L 1.8L 2003-2007
Part Number: 16361-0D070 Product Name: Radiator Cooling Fan Blade Assembly
Car Model: Toyota Corolla Altis Engine Model: Toyota 1.6L 1.8L
Condition: 100% Brand New Size: Standard
Weight: Standard Origin: China Mainland
Main Market: Middle East, Asia, Africa, South America, North America & Europe
Package: Neutral Packing Or Make It As Requested
Material: High-strength aluminum alloy & precision bearings
Installation: Direct OEM replacement Quality Standard: OEM equivalent / ISO quality control
Vehicle Appliions

This Toyota Corolla radiator fan blade 16361-0D070 directly replaces the factory component in the following configurations:

Model Generation / Chassis Engine Years
Toyota Corolla E120, E130 (IX, 9th Gen) 1.4 VVT-i, 1.6 VVT-i, 1.8 VVT-i 2001 - 2008
Toyota Corolla Altis E120, E130 1.6L, 1.8L 2001 - 2007
Toyota Corolla Estate E120 1.4 VVT-i, 1.6 VVT-i 2001 - 2008
Important component breakdown: The 16361-0D070 is a fan blade replacement, typically sold as part of a complete fan assembly that includes:
  • Fan blade: 16361-0D070 - the rotating part that moves air
  • Fan motor: 16363-23020 - the electric motor that drives the blade
  • Fan shroud: 16711-21050 - the plastic housing that directs airflow

If the motor or shroud is also damaged, the complete assembly may be required. If only the fan blade is cracked or broken, this individual blade is the correct replacement.

Common Failure Symptoms

The Corolla cooling fan is subjected to constant thermal cycling and can suffer from:

  • Cracked or broken blades from debris impact, age, or thermal fatigue
  • Blade deformation from heat exposure, causing imbalance and noise
  • Motor bearing failure leading to blade wobble (requires motor replacement, OE 16363-23020)
Recommended Replacement Indiors
Symptom Diagnosis
Rising engine temperature gauge in traffic or at idle Fan not moving enough air - check for damaged or missing blades
A/C blows warm at stoplights but cools when driving Insufficient airflow through condenser at low speeds - common fan blade or motor failure
Loud grinding or rattling noise from the radiator area Fan blade contacting shroud - likely bent or broken blade
Engine overheating when A/C is on Cooling fan not producing enough airflow - inspect blade for damage
Visible cracks, missing sections, or melted plastic on the fan blade Physical damage - immediate replacement required
Features & Benefits
Direct OE Replacement for E120 Corolla This fan blade carries the exact Toyota part number 16361-0D070 and is listed in aftermarket alogues as a direct replacement for the E120 series Corolla.
360 mm Diameter - Matches Factory Specifiion The blade has a diameter of 360 mm, matching the original Corolla factory specifiion. The 5-blade design matches the original fan configuration.
Part of Complete Assembly This blade is supplied as a standalone replacement. The motor (16363-23020) and shroud (16711-21050) are available separately.
Compatible with Aftermarket and OE Motor Units The blade is designed to fit the OE Toyota motor (16363-23020) and also works with aftermarket equivalents.
Restores Cooling and A/C Performance Replacing a damaged fan blade restores proper cooling, preventing engine overheating and ensuring effective air conditioning at idle.
Quality Control & Verifiion

Each batch of the Toyota Corolla radiator fan blade 16361-0D070 undergoes the following verifiions at the OE supplier level:

QC Item Verifiion Method
Blade diameter Precision measurement - 360 mm ±2 mm
Number of blades 100% visual verifiion - 5-blade design
Blade pitch and geometry Go/no-go fixture - matches OE specifiion
Material composition Heat deflection temperature test - nylon grade confirmed
Dynamic balance Spin-balanced at operating speed - residual imbalance within OE tolerance
Blade tip clearance Fixture check - correct clearance relative to shroud mounting points
Full dimensional inspection CMM measurement - blade profile, mounting hole pattern, and hub geometry

A certifie of conformance with batch test data is available for wholesale orders.

Packaging & Supply
  • Individual packaging: Sealed in anti-static VCI bag, foam-lined carton
  • Carton dimensions: Approximately 40 × 40 × 10 cm
  • Net weight: Approximately 0.8-1.2 kg
  • Master carton: 50 units per export carton
  • Lead time: 3-7 working days for stock orders; 15-25 days for production orders above 200 pieces
  • Minimum order quantity: 1 piece (sample order available)
  • Shipping methods: FedEx, UPS, DHL for sample quantities; sea freight (LCL/FCL) from Shanghai, Ningbo, Guangzhou ports
  • H/S Code: 8414.59

For workshops performing a full cooling system service, the supplier also stocks matching fan motors (16363-23020) and fan shrouds (16711-21050) for the Corolla E120 platform. Contact the sales team with your forecasted monthly volume and destination port for a tiered price list.

Quick Summary

The Toyota Corolla Altis radiator cooling fan blade 16361-0D070 is an OE-specifiion replacement for the E120/E130 series Corolla (2001-2008). The 360 mm, 5-blade design matches the factory specifiion and is compatible with OE motor 16363-23020 and aftermarket equivalents.

Before ordering: This is a fan blade replacement only. If the motor or shroud is also damaged, order the motor (16363-23020) or shroud (16711-21050) separately. Confirm vehicle fitment for E120/E130 Corolla (2001-2008) before ordering.

Order a sample unit today - restore your Corolla's cooling performance without replacing the entire fan assembly.
