Multi-Layer Steel (MLS) Cylinder Head Gasket 1.1mm Thickness for Toyota 2KD-FTV 2.5 D-4D Engine
Multi-Layer Steel (MLS) Cylinder Head Gasket 1.1mm Thickness for Toyota 2KD-FTV 2.5 D-4D Engine
Specifications
Payment Terms :
T/T,
Gasket Type :
Multi-Layer Steel (MLS)
Model Number :
Toyota 2KD-FTV 2.5 D-4D
Width :
183 mm
MOQ :
10 pcs
Delivery Time :
5-8 Work Days
Diameter :
93.5 mm
Price :
Negotiable
Notches :
5 notches (Mark E)
Certifiion :
ISO/TS16949
Length :
470 mm
Supply Ability :
10000 pcs/month
Material :
High-strength aluminum alloy & precision bearings
Brand Name :
YIMI
Thickness Range :
1.000–1.100 mm
Packaging Details :
Neutral Package or as customers’ request
Place of Origin :
China
Nominal Thickness :
1.1 mm
Description
Product Overview

The Cylinder Head Gasket with OEM reference number 11115-30040-E0 is a verified direct-fit replacement for the Toyota 2KD-FTV 2.5L D-4D common rail turbo-diesel engine. This critical sealing component sits between the engine block and cylinder head, withstanding extreme temperatures and pressures.

Part Number:
11115-30040-E0
Product Name:
Cylinder Head Gasket
Car Model:
Toyota Hilux
Engine Model:
Toyota 2KD-FTV 2.5 D-4D
Condition:
100% Brand New
Thickness Grade Reference

This gasket is available in multiple thickness grades identified by notches/holes. Selection is based on measured piston protrusion.

Mark Notches Thickness Range Nominal Thickness OE Number
Mark A 1 notch 0.800-0.900 mm 0.9 mm 11115-30040-A0
Mark B 2 notches 0.850-0.950 mm 0.95 mm 11115-30040-B0
Mark C 3 notches 0.900-1.000 mm 1.0 mm 11115-30040-C0
Mark D 4 notches 0.950-1.050 mm 1.05 mm 11115-30040-D0
Mark E 5 notches 1.000-1.100 mm 1.1 mm 11115-30040-E0
Vehicle Compatibility
Primary Appliions (Toyota 2KD-FTV 2.5 D-4D Engine):
Brand Model Chassis / Series Years
Toyota Hilux / 4Runner Truck KUN25, KUN35 (Vigo) 2005-2011
Toyota HiAce H100, H200 (KLH12, KLH22) 2006-2012
Toyota Dyna / Toyoace Various Various
Toyota Fortuner Various Various
Toyota Innova / Kijang / Revo / Unser / Zace Various Various
Important: Always verify the correct thickness grade for your specific engine appliion. The required grade depends on piston protrusion measurements.
Features & Benefits
Feature Benefit
Multi-Layer Steel (MLS) construction Superior sealing performance under extreme turbo-diesel temperatures and pressures
Precision-engineered E-grade (1.1mm) thickness Correct thickness for engines with higher piston protrusion (0.205-0.255mm)
93.5mm diameter with 183 x 470mm dimensions Precision fit for 2KD-FTV engine - matches factory specifiions exactly
5-notch identifiion Clear visual identifiion of E-grade thickness - eliminates installation errors
Genuine OEM / OEM-grade quality Manufactured to Toyota's exacting standards - ensures perfect fit and reliable performance
Proven durability Engineered for long service life under demanding turbo-diesel operating conditions
100% quality inspected Reliable out of the box - each unit verified for dimensional accuracy and material integrity
Installation & Maintenance Recommendations
IMPORTANT: Cylinder head gasket replacement requires mechanical competence and proper torque procedures. Professional installation strongly recommended.
When to Replace:
  • Engine overheating or coolant loss
  • White exhaust steam (coolant burning)
  • Oil/coolant cross-contamination (milky substance on oil cap)
  • Loss of compression or reduced engine power
  • During complete engine overhaul or rebuild
Installation Guidelines:
  1. Safety first - allow engine to cool completely before starting work
  2. Drain engine oil and coolant
  3. Remove cylinder head following manufacturer sequence
  4. Thoroughly clean both the cylinder block and cylinder head sealing surfaces
  5. Inspect the cylinder head and block for flatness
  6. Check cylinder head bolt threads - clean and inspect for damage
  7. Measure piston protrusion - determine the correct gasket grade
  8. Verify correct thickness - confirm that E-grade (5-notch, 1.1mm) is correct
  9. Place the new cylinder head gasket on the cylinder block
  10. Install cylinder head and torque bolts to manufacturer specifiion
  11. Reassemble all components, refill with fresh oil and coolant
  12. Start engine, check for leaks, and perform break-in procedure
